Chimney (flue) base tee, L vent. Prefabricated double-wall metal gas or propane fuel chimney base
tee with cap. Stainless steel inner liner with extruded aluminum outer jacket. High temperature and
condensing boiler or furnace applications. Maximum flue temperature of 750 degrees F. Check local
codes for regulations regarding acceptable installation requirements.
5" double wall P1@.165 Ea 87.26 6.55 93.81
6" double wall P1@.180 Ea 93.43 7.14 100.57
7" double wall P1@.195 Ea 112.11 7.74 119.85
8" double wall P1@.220 Ea 124.23 8.73 132.96

Chimney (flue) elbow, L vent. Prefabricated double-wall metal gas or propane fuel chimney. Stainless
steel inner liner with extruded aluminum outer jacket. High temperature and condensing boiler or furnace
applications. Maximum flue temperature of 750 degrees F. Check local codes for regulations regarding
acceptable installation requirements.
5" double wall, 45-degree elbow P1@.165 Ea 68.28 6.55 74.82
5" double wall, 90-degree elbow P1@.165 Ea 99.18 6.55 105.73
6" double wall, 45-degree elbow P1@.180 Ea 73.53 7.14 80.67
6" double wall, 90-degree elbow P1@.180 Ea 103.02 7.14 110.16
7" double wall, 45-degree elbow P1@.195 Ea 103.02 7.74 110.76
7" double wall, 90-degree elbow P1@.195 Ea 67.06 7.74 74.80
8" double wall, 45-degree elbow P1@.220 Ea 82.21 8.73 90.94
8" double wall, 90-degree elbow P1@.220 Ea 118.17 8.73 126.90

Chimney (flue) storm collar, rain cap and roof flashing assembly, L vent. Prefabricated
double-wall metal gas or propane fuel chimney. Stainless steel inner liner with extruded aluminum outer
jacket. High temperature and condensing boiler or furnace applications. Maximum flue temperature of
750 degrees F. Check local codes for regulations regarding acceptable installation requirements.
5" double wall, termination assembly P1@.700 Ea 103.02 27.77 130.79
6" double wall, termination assembly P1@.750 Ea 119.18 29.75 148.93
7" double wall, termination assembly P1@.900 Ea 133.32 35.70 169.02
8" double wall, termination assembly P1@1.15 Ea 160.59 45.62 206.21

Chimney (flue), A vent. Prefabricated double-wall insulated stainless steel all-fuels chimney.
Maximum flue temperature of 1,700 degrees F. Stainless steel inner liner and outer jacket. Twist-lock
connection. Add for cutting new holes in ceiling and roof, and patching, if required. Check local codes
for regulations regarding acceptable installation requirements.
5" double wall P1@.120 LF 44.74 4.76 49.50
6" double wall P1@.125 LF 47.77 4.96 52.73
7" double wall P1@.140 LF 50.00 5.55 55.55
8" double wall P1@.145 LF 53.43 5.75 59.18
10" double wall P1@.160 LF 86.25 6.35 92.60
Add for 2,100 degree maximum temp rating -- % 45.0 -- --

Chimney (flue) base tee, A vent. Prefabricated double-wall insulated all-fuels chimney base tee
including cap. Maximum flue temperature of 1,700 degrees F. Stainless steel inner liner and outer
jacket. Twist-lock connection. Add for cutting new holes in ceiling and roof and patching, if required.
Check local codes for regulations regarding acceptable installation requirements.
5" double wall P1@.170 Ea 194.93 6.74 201.67
6" double wall P1@.185 Ea 209.07 7.34 216.41
7" double wall P1@.200 Ea 220.18 7.93 228.11
8" double wall P1@.225 Ea 231.29 8.93 240.22
10" double wall P1@.260 Ea 275.73 10.31 286.04
Add for 2,100 degree F. maximum temp rating -- % 25.0 -- --
