2018 National Home Improvement Estimator, All Rights Reserved Page 403

Chimney (flue) elbow, A vent. Prefabricated double-wall insulated all-fuels chimney elbow. Maximum
flue temperature of 1,700 degrees F. Stainless steel inner liner and outer jacket. Twist-lock connection.
Add for cutting new holes in ceiling and roof and patching, if required. Check local codes for regulations
regarding acceptable installation requirements.
5" double wall, 15-degree elbow P1@.170 Ea 72.42 6.74 79.16
5" double wall, 30-degree elbow P1@.170 Ea 76.15 6.74 82.90
5" double wall, 45-degree elbow P1@.170 Ea 109.08 6.74 115.82
6" double wall, 15-degree elbow P1@.190 Ea 74.94 7.54 82.48
6" double wall, 30-degree elbow P1@.190 Ea 78.88 7.54 86.42
6" double wall, 45-degree elbow P1@.190 Ea 100.39 7.54 107.93
7" double wall, 15-degree elbow P1@.225 Ea 85.85 8.93 94.78
7" double wall, 30-degree elbow P1@.225 Ea 93.32 8.93 102.25
7" double wall, 45-degree elbow P1@.225 Ea 119.18 8.93 128.11
8" double wall, 15-degree elbow P1@.260 Ea 102.01 10.31 112.32
8" double wall, 30-degree elbow P1@.260 Ea 111.10 10.31 121.41
8" double wall, 45-degree elbow P1@.260 Ea 133.32 10.31 143.63
10" double wall, 15-degree elbow P1@.330 Ea 122.21 13.09 135.30
10" double wall, 30-degree elbow P1@.330 Ea 140.39 13.09 153.48
10" double wall, 45-degree elbow P1@.330 Ea 170.69 13.09 183.78
Add for 2,100 degree maximum temp rating -- % 25.0 -- --

Chimney (flue) storm collar, rain cap and roof flashing assembly, A vent. Prefabricated
double-wall insulated all-fuels chimney. Maximum flue temperature of 1,700 degrees F. Twist-lock
connection. Add for cutting new holes in ceiling and roof, and patching, if required. Check local codes
for regulations regarding acceptable installation requirements.
5" double wall, termination assembly P1@.750 Ea 122.21 29.75 151.96
6" double wall, termination assembly P1@.800 Ea 136.35 31.74 168.09
7" double wall, termination assembly P1@.950 Ea 144.43 37.69 182.12
8" double wall, termination assembly P1@1.20 Ea 160.59 47.60 208.19
10" double wall, termination assembly P1@1.30 Ea 188.87 51.57 240.44

Chimney (flue) supports and brackets, A vent. Prefabricated double-wall insulated all-fuels chimney.
Maximum flue temperature of 1,700 degrees F. Twist-lock connection. Add for cutting new holes in
ceiling and roof, and patching, if required. Check local codes for regulations regarding acceptable
installation requirements.
5" double wall, anchor plate P1@.200 Ea 41.71 7.93 49.65
5" double wall, adjustable wall support P1@.300 Ea 67.17 11.90 79.07
5" double wall, wall or floor support P1@.400 Ea 46.66 15.87 62.53
6" double wall, anchor plate P1@.225 Ea 45.35 8.93 54.28
6" double wall, adjustable wall support P1@.325 Ea 84.64 12.89 97.53
6" double wall, wall or floor support P1@.425 Ea 70.20 16.86 87.06
7" double wall, anchor plate P1@.230 Ea 48.18 9.12 57.30
7" double wall, adjustable wall support P1@.330 Ea 94.94 13.09 108.03
7" double wall, wall or floor support P1@.430 Ea 62.62 17.06 79.68
8" double wall, anchor plate P1@.240 Ea 51.01 9.52 60.53
8" double wall, adjustable wall support P1@.350 Ea 109.08 13.88 122.96
8" double wall, wall or floor support P1@.450 Ea 74.54 17.85 92.39
10" double wall, anchor plate P1@.260 Ea 85.55 10.31 95.86
10" double wall, adjustable wall support P1@.400 Ea 130.29 15.87 146.16
10" double wall, wall or floor support P1@.550 Ea 105.04 21.82 126.86
