Service Area

Bain Marie 5+2

FEATURES

 SS 304 16 gauge Top Provide with 5 Hot 1/1 GN

Pan and 2 Ambient 1/1 GN Pan.
 Top secured to TIG welded 35x35x5mm thick
M.S Angle Framework.

 SS trough for Hot Bain Marie made from SS-304
18 gauge with Ball Valve releasing wastage
water.
 For Heating Purpose use 3 KW Electrical Heater
in Water Tank.

 Back Side provide control panel with Thermostat
for Temperature control and ON/ OFF Switch.
 Side Covering and U/S are made from 18 Gauge
SS -304.
 4 Nos. Legs are 16 Gauge SS 304 30x30x1.5 SQ.

Pipe.

MODEL  Adjustable Nylon bullet feet to accommodate
BM5+2 L X W X H (MM) uneven flooring.
 Hygienic convenient and easy to clean.
BM5+2 2500 X 650 X 850
 Also available in Taylor made designs and sizes.
