HAND - LEVER GREASE GUN

• For 500 cm bulk grease, 400 g cartridges,
3
(235 x Ø 53.5 mm).
• Feed volume adjustable up to 1.5 cm .
3
• Operating pressure 400 bar.
• Maximum pressure up to above 800 bar.
• Actuating force 50 to 330 N at feed
pressures of 50 to 400 bar.

B
C
A
Description Art. No. Pack Qty.
Hand-Lever Grease Gun includes A,B,C 0986 00 1
Replacement Parts:
A. Metal Connector 0986 001 1
B. Reinforced Flexible Hose 0986 002
C. Nose Piece (M10 x 1) 0986 003

4 7

3

1 2 5 6 8 10 9

1. Precision steel pump, no “false lubrication”, no seals to wear out.
2. Short stroke feed system, grease feed possible at any opening angle, two inlet openings, good
grease flow even at low temperatures.
3. Filling and air bleeding valve. Filling possible with cartridges or bulk grease with filling device.
4. Metering gauge for controlled grease output.
5. Grease and oil resistant special seal piston.
6. Sturdy precision tube.
7. Ergonomically designed safety handle.
8. No-slip knurling in the grip area.
9. Closed piston rod handle.
10. Fixing system - infinitely adjustable, slip-proof piston rod fixing - no inadvertent operation.

The design corresponds to DIN 1283 (M10 x 1) and has been certified by TÜV/GS, BLT and DLG.
