coil tubing

For bundling and protection of wires.

• Highly flexible coil tubing replaces continual
cable tying.
• Ideal for adding further cables and wires as
no firm ties have to be cut.
• Coiled structure allows for branching off any
point with out distorting the excellent overall
impression.
• Re-useable.
• No tools required.
• Self extinguishing.
• Temperature resistance: -30°C up to 80°C.

Internal ø Suits Bundle Wall Thickness Helix Width Colour Art. No. Pack
mm ø mm mm mm Qty.
8.2 12.0 - 50.0 0.90 12.0 Black 0771 00 80
17.6 20.0 - 120.0 1.20 22.0 Black 0771 00 90 25 m

Colour Black
Material Polypropylene, halogen-free
Temperature stability - 30 C to 80 C (without mechanical load)
o
o
Flammability according to UL94 HB
