Diagnosis - Diagnosis-fault diagnosis of electronic and electrical parts DI - 201
Check if the result is ok? IN
Yes>go to Step 3.
NO>repair or replace the open harness DI
3. Check the radio cassette player
Caution EG
If the assembly of radio cassette player is broken, non-professional personnel normally cannot timely
and precisely check and test it. At present often using the substitution judgment method for service TR
a. Replace with a new or normal radio cassette player
AX
b. Connect the circuit, restart the radio cassette player and check if the failure is fixed.
Caution
The radio cassette player for replacement must be the same specification as previously used FR
Is the test result ok?
ST
Yes>repair or replace the radio cassette player
Caution
BR
It requires professional personnel to perform service for the inside of radio cassette player.
Non-professional personnel shall not dismount.
BW
NO>retest the above steps
EL
DI-201
