DIAGNOSTICS - VEHICLE CONTROL SYSTEM 04-991
(c) Measure the electrical resistance based on
the value in the following form.
Standard electrical resistance (check
whether there existent an open circuit)
1 Ḥ 2 3 4 Ḥ 5 C034
Ḥ
6 Ḥ 7 8 9 10 11 12 Multimeter connection Specified value
stitch 04
F36(10A) - C034
7.5A 7.5A 10A 5A 20A 7.5A C037 ＜ 2 Ω
F41 （C10）
F30 F31 F32 F33 F35 F34 86
F40 R01
7.5A 10A 5A 85
F39 25A
F24 F25 F26 F27 F28 F29 30 87
F38 15A 87A
F37 10A 15A 7.5A 10A
F36 15A F19 F21 F18 F20 F22 F23 R07 86
20A 25A 5A
ftwxd041334
Check whether the result is normal?
Yes> Replace BCM control unit.
No > Maintenance or replace harness.
