FEATURES APPLICATIONS OPTIONS
n Produces particles within n Cellulose n Carbon steel, #304 stainless
narrow size ranges from n Cereals steel, and #316 stainless steel
10 to 100 mesh construction
n High throughput-to- n Cocoa n Food grade sanitary construction
horsepower ratio n Corn cracking/de-germinating with #4 to #7 interior surface
n Rotating disc and shaft n Grains finishes and internal polished
assembly supported by radial n Feather curling welds from 120 to 240 grit
and thrust-load-rated pillow n Several plate designs for
block ball bearings n Fiber fluffing specific purposes: Radial Rib,
n Adjustable grinding plate n Metal powder conditioning Radial Undercut Rib, Spiral Rib,
Model SK-30-SS Sanitary Attrition spring pressure assures reduction/recycling Oval Rib, and Devil’s Tooth,
Mill with stainless steel housings product uniformity n Minerals amongst others, with custom
and support structure cleans designs available
quickly, easily. n Several milling disc n Mustard seed n Plates constructed of grey iron,
patterns available to optimize n Nutmeg
size reduction for specific Ni-Hard, hardened stainless
material types n Peanuts/peanut butter steel, SH-100, and other
materials
n Quick-release separation n Pepper
of discs allows mill to be n Seed and bean hulling n Replaceable abrasion-resistant
opened without need and/or reduction steel internal housing liners
readjust plate gap n Tobacco stems n Transitions for gravity discharge
n Spring loading allows runner and pneumatic collection
disc to be forced away from n Various food products n Controls packages for start/
stator disc to allow passage n Various roots and spices stop and variable rotor speeds
of hard foreign substances n Direct forced screw feeding
n Access doors allow easy
Rear of carbon steel model SK- clean-out, maintenance,
24-MS Attrition Mill showing hand inspection
wheel with lock ring and gap gauge
for adjusting the gap between discs. n Compact overhead motor-
mounted drive with V-belt
arrangement as standard
n Fully enclosed drive guards
and limit switches for INLET
INLET
operator safety
n Discs are cast or CNC
machined of Ni-Hard alloy, HEIGHT
®
and then machined on a HEIGHT
blanchard grinder for MUNSON
absolute flatness
n Carbon steel machines
come standard with cast
sectioned disc plates of DISCHARGE
Material enters through the center carbon steel or various DISCHARGE
of the outer disc and travels radially alloys including Ni-Hard LENGTH WIDTH
WIDTH
LENGTH
®
as it is milled between the discs. (one-piece discs optional)
n Sanitary stainless steel SPECIFICATIONS
machines come standard
with one-piece, machined MODEL RPM DISC DIA. LENGTH HEIGHT WIDTH HP/KW
stationary and rotating discs RANGE IN/MM IN/MM IN/MM IN/MM
n Port for direct plate gap
measuring SK 12 900-2400 12/305 52/1321 20/508 36/914 10-15/7-11
SK 24 900-2000 24/610 63/1600 30/762 38/965 15-25/11-19

SK 30 900-1800 30/762 65/1651 36/914 52/1321 30-50/22-37
SK 36 900-1800 36/914 71/1803 49/1245 67/1702 40-60/30-45
Cast grinding plates in a various
sizes, designs, and materials
including Ni-Hard , brass, bronze, Technical data can be altered without prior notice. Given measurements must
®
not be used for engineering.
and SH-100 hardened cast iron.
