SMARTCRAFT RIGGING



            ACTIVE TRIM - 75-115HP FOURSTROKE - DUAL ENGINE     DIGITAL TRIM SENDER KIT - 75-115HP FOURSTROKE
            (WITHOUT TRIM PAD)












                                                                     8M0109722
                 8M0129456                                      Digital Trim Sender Kit
            The Active Trim Kit includes the ECU, harness and digital trim sender.  Active Trim  1.7L 75‑115HP FourStroke
            part numbers are specific to engine families.  Ensure correct kit is ordered.
            Additional parts may be required dependent on boat rigging.  TRIM SENSOR CONVERTER KIT
            Dual Engine 75‑115HP FourStroke and using a VesselView 502 or 702 and newer
            display or using a VesselView Link and Lowrance or Simrad display. (SN
            2B095049 and up)
            ACTIVE TRIM - MECHANICAL MERCRUISER - DUAL
      SMARTCRAFT RIGGING
            ENGINE (WITHOUT TRIM PAD)





                                                                     8M0059529
                                                                This kit will allow you to convert the signal from the digital sensor to an analog
                                                                signal.  It will allow you to drive an analog gauge for trim only without changing the
                                                                sensor to an analog sensor.  This kit will connect directly to the harness inside the
                                                                emgine cowl.
                                                                F150 EFI FourStroke outboard engine only
                 8M0129458
            The Active Trim Kit includes the ECU and harness.  Active Trim part numbers are  DIGITAL TO ANALOG CONVERTER
            specific to engine families.  Ensure correct kit is ordered.  Additional parts may be
            required dependent on boat rigging.
            Dual Engine Mechanical Sterndrive 4.5L and 6.2L 300 & 350HP only and using a
            VesselView 502 or 702 and newer display or using a VesselView Link and
            Lowrance or Simrad display.
            ACTIVE TRIM - PAD ONLY






                                                                     8M0111837
                                                                Enables use of analog trim gauge with digital trim sender
                                                                F2 40‑60 HP FourStrokes, 2.1L 75‑115 HP FourStrokes and Optimax V6
                                                                ACTIVE TRIM SIDE MOUNT ADAPTER KIT
                 8M0112041
            Active trim pad for second helm and/or service replacement
            DIGITAL TRIM SENDER KIT - 40-60HP FOURSTROKE









                                                                   84-8M0114502
                                                                Kit contains bullet to Molex connector to make Active Trim compatible with
                                                                mechanical side mount control
                                                                Only required on boats utilizing mechanical side mount control
                 8M0109720
            Digital Trim Sender Kit
            40‑60HP FourStroke
