Page 570 - Quicksilver Accesories Guide 2019

SMARTCRAFT RIGGING

SMARTCRAFT PITOT SENSOR KIT
GPS KITS
SMARTCRAFT OR NMEA2000 GPS ANTENNA

8M0090447
Pitot sensor kit provides speed information for SmartCraft gauges.
2.1L F75‑115 Four Stroke and 150 Four Stroke
8M0130792
SMARTCRAFT PITOT SENSOR (SPEED) SmartCraft or NMEA2000 capable GPS Antenna. Used with any system needing a
SmartCraft GPS source OR NMEA2000 GPS source. GPS autodetects which
system it is connected to and communicates correctly.
GPS can be used for all of the following applications: SC1000 gauge speed source,
SmartTow speed source, Active Trim without dash pad speed source or
NMEA2000 speed and position source.
GPS EXTENSION CABLE SMARTCRAFT RIGGING

8M0103315
100 psi SmartCraft Pitot sensor for speed input
Verado Gen 5 350 HP engine only, all other Gen 5 Verado engines come with Pitot
speed sensor
PRESSURE TRANSDUCER KIT
84-879171T21
3.2 foot extension cable to be used with GPS Kit (8M0024918)
CAN P GPS signal for non Auto Pilot equipped boats
84-879171T22
6.6 foot extension cable to be used with GPS Kit (8M0024918)
CAN P GPS signal for non Auto Pilot equipped boats
84-879171T23
9.8 foot extension cable to be used with GPS Kit (8M0024918)
CAN P GPS signal for non Auto Pilot equipped boats
CAN H TO GTC CONNECTOR ADAPTER HARNESS
859210A 1
Speed pressure transducer is either mounted to the transom bracket or a location
near the engine. 100 PSI sensor is plumbed to a speed pickup tube and then wired
to the engine sensor plug included with SmartCraft Gauges.
Fits 2002 and newer OptiMax outboard engines at speeds less than 80 mph.

84-8M0120136
Flat 4 pin CAN H connector to GTC connector adapter ‑ 0.5 meter
Used in certain Joystick applications

Not all parts listed are available for the European, C.I.S., Africa and Middle East Markets. 563
For more information, please contact your local Mercury, Mariner, MerCruiser or
Quicksilver Office.
