ELECTRICAL

QUAD ENGINE START/STOP PAD - PORT START/STOP EXTENSION HARNESS

87-8M0117140 84-896380T05
Low profile mount quad engine start/stop pad (PORT) which allows start and stop 5 ft. Allows you to extend the harness an extra 5 ft from the start/stop button
of engines with keyswitches in the RUN position. Used on all DTS engines.
Can be used on all quad engine DTS applications (PORT)
BEZEL KEY SWITCHES
KEY SWITCH -3 POSITION WITH DECAL/WASHER

879315T01
Black
Start/Stop switch kit, flush mount. For single, dual, triple and quad application. 87-897716K01
Three position keyswitch with shorter key and mounting length (Off, Run and Start)
BEZEL Loose switch only. 3/4 in. cut out. Includes switch with decal and washer.
Can be used on DTS as well as Non DTS installations.
KEY SWITCH -3 POSITION WITH DECAL/WASHER

ELECTRICAL White 879315T02

Start/Stop switch kit, flush mount. For single, dual, triple and quad application.
87-897716K02
BEZEL Three position keyswitch with shorter key and mounting length (Off, Run and Start)
Loose switch only. 3/4 in. cut out. Includes switch with decal and washer.
Matched set for dual engine installs
Can be used on DTS as well as Non DTS installations. Matched keyswitches for
dual installations

879315T03
Chrome
Start/Stop switch kit, flush mount. For single, dual, triple and quad application.
