Page 595 - Quicksilver Accesories Guide 2019

ELECTRICAL

84-816626A24 84-8M0125755
25 ft.(7.6 m) harness with audio warning horn. 30 foot harness with horn, push to choke key switch, instrumentation connector,
Fits Mercury / Mariner 6 hp. and Higher (2 cycle, USA & BEL Origin) outboards, trim connector and lanyard connector
Mariner 30/40 hp. with oil injection (2 cycle, Japanese Origin), all Mercury / Mariner Connects to 8 pin AMP connector engines (8/9.9 HP FourStrokes and similar)
4‑Stroke (USA Origin) outboards, Force 40 hp. and Higher (1993 and Newer) and single engine.
Mercury Jet Drives. When used with MY2005 and newer 8/9.9 hp. FourStroke
outboards an adapter harness 892473A01 is required. 8 PIN KEY SWITCH AND IGNITION HARNESS
84-816626A25
25 ft.(7.6 m) harnesses with audio warning horn. Packaged with 2 harnesses with
matched keys for dual engine applications.
Fits Mercury / Mariner 6 hp. and Higher (2 cycle, USA & BEL Origin) outboards,
Mariner 30/40 hp. with oil injection (2 cycle, Japanese Origin), all Mercury / Mariner
4‑Stroke (USA Origin) outboards, Force 40 hp. and Higher (1993 and Newer) and
Mercury Jet Drives.
84-816626A29
30 ft.(9.1 m) harnesses with audio warning horn.
Fits Mercury / Mariner 6 hp. and Higher (2 cycle, USA & BEL Origin) outboards,
Mariner 30/40 hp. with oil injection (2 cycle, Japanese Origin), all Mercury / Mariner
4‑Stroke (USA Origin) outboards, Force 40 hp. and Higher (1993 and Newer) and
Mercury Jet Drives. 84-8M0125754
84-816626A30 25 foot harness with horns, push to choke key switches, instrumentation
30 ft.(9.1 m) harnesses with audio warning horn. Packaged with 2 harnesses with connectors, trim connectors and lanyard connectors
matched keys for dual engine applications. Connects to 8 pin AMP connector engines (8/9.9 HP FourStrokes and similar)
Fits Mercury / Mariner 6 hp. and Higher (2 cycle, USA & BEL Origin) outboards, Dual Engine Application.
Mariner 30/40 hp. with oil injection (2 cycle, Japanese Origin), all Mercury / Mariner
4‑Stroke (USA Origin) outboards, Force 40 hp. and Higher (1993 and Newer) and 84-8M0125756
Mercury Jet Drives. 30 foot harness with horns, push to choke key switches, instrumentation
connectors, trim connectors and lanyard connectors
8 PIN KEY SWITCH AND IGNITION HARNESS Connects to 8 pin AMP connector engines (8/9.9 HP FourStrokes and similar).Dual
Engine Application.
KEY SWITCH W/ HARNESS - NON DTS 14 PIN

84-8M0125748
2 foot harness with horn, push to choke key switch, instrumentation connector, trim
connector and lanyard connector
Connects to 8 pin AMP connector engines (8/9.9 HP FourStrokes and similar) 84-896537K02
‑Single Engine Application. 2 ft. harness (896537A02) with new 14 pin connector for the engine and additional
84-8M0125749 connectors that allow easy quick connect solutions to the rigging process. Included
in this kit is also the new 3 position water‑proof high quality keyswitch. (897716)
ELECTRICAL connector and lanyard connector 2006 and newer Non DTS Outboards from 25 Hp to 250 HP‑ 14 Pin Connectors
8 foot harness with horn, push to choke key switch, instrumentation connector, trim
All MCM / MIE engines equiped with 14 pin connectors
Connects to 8 pin AMP connector engines (8/9.9 HP FourStrokes and similar)
84-896537K08
‑Single Engine Application.
84-8M0125750
connectors that allow easy quick connect solutions to the rigging process. Included
11 foot harness with horn, push to choke key switch, instrumentation connector, 8 ft. harness (896537A08) with new 14 pin connector for the engine and additional
in this kit is also the new 3 position water‑proof high quality keyswitch. (897716)
trim connector and lanyard connector 2006 and newer Non DTS Outboards from 25 Hp to 250 HP‑ 14 Pin Connectors
Connects to 8 pin AMP connector engines (8/9.9 HP FourStrokes and similar) All MCM / MIE engines equiped with 14 pin connectors.
‑Single Engine Application. 84-896537K11
84-8M0125751 11 ft. harness (896537A11) with new 14 pin connector for the engine and
15 foot harness with horn, push to choke key switch, instrumentation connector, additional connectors that allow easy quick connect solutions to the rigging
trim connector and lanyard connector process. Included in this kit is also the new 3 position water‑proof high quality
Connects to 8 pin AMP connector engines (8/9.9 HP FourStrokes and similar) keyswitch. (897716)
‑Single Engine Application. 2006 and newer Non DTS Outboards from 25 Hp to 250 HP‑ 14 Pin Connectors
84-8M0125752 All MCM / MIE engines equiped with 14 pin connectors.
20 foot harness with horn, push to choke key switch, instrumentation connector, 84-896537K15
trim connector and lanyard connector 15 ft. harness (896537A15) with new 14 pin connector for the engine and
Connects to 8 pin AMP connector engines (8/9.9 HP FourStrokes and similar) additional connectors that allow easy quick connect solutions to the rigging
‑Single Engine Application. process. Included in this kit is also the new 3 position water‑proof high quality
84-8M0125753 keyswitch. (897716)
25 foot harness with horn, push to choke key switch, instrumentation connector, 2006 and newer Non DTS Outboards from 25 Hp to 250 HP‑ 14 Pin Connectors
All MCM / MIE engines equiped with 14 pin connectors.
trim connector and lanyard connector
Connects to 8 pin AMP connector engines (8/9.9 HP FourStrokes and similar)
‑Single Engine.
588 2019 Quicksilver Precision Parts & Accessories Guide
