SHADOW RESISTOR PACKS RESISTOR PACK #98 ASSEMBLY - QUAD SHADOW
MODE
RESISTOR PACK- DTS SHADOW MODE
898091T04
Resistor pack #98 used with Quad DTS Shadow control dual helm applications.
898091T01 (#98) Helm 2, Port 2
Resistor pack used with DTS Shadow Mode applications. (#93) Included with the Quad engine / dual helm applications 2006 models and newer.
harness for this versions Helm 1, Starboard 2
Triple engine / single helm applications 2006 models and newer
JUNCTION BOXES/JUNCTION BOX ACCESSORIES
RESISTOR PACK #94 - QUAD DTS SHADOW MODE
SMARTCRAFT JUNCTION BOX
898091T02
Resistor pack #94 used on Quad DTS Shadow control single helm applications. 878492K14
Helm 1, Port 2 4‑Way SmartCraft Junction Box with (2) weather caps.
Quad engine / single helm applications 2006 models and newer Provides connection/distribution point for multiple components on CAN Bus
RESISTOR PACK- DTS SHADOW MODE system.
878492T14
4‑Way SmartCraft Junction Box without weather caps.
Provides connection/distribution point for multiple components on CAN Bus
system.
878492B14
4‑Way SmartCraft Junction Box without weather caps.
Provides connection/distribution point for multiple components on CAN Bus
system.
Priced individually, sold @ multiples of 24 ELECTRICAL
SMARTCRAFT JUNCTION BOX
898091T03
Resistor pack used with DTS Shadow Mode applications. (#97) Helm 2,
Starboard 2
Included in lower or primary helm for dual helm installs (895816A, 895817A,
895818A, and 895819A series helms)
Triple engine / dual helm applications 2006 models and newer.
878492K16
6‑Way SmartCraft Junction Box with (3) weather caps.
Provides connection/distribution point for multiple components on CAN Bus
system. Order 1 for single and 2 for twin engine installs.
878492T16
6‑Way SmartCraft Junction Box without weather caps.
Provides connection/distribution point for multiple components on CAN Bus
system.
