Page 636 - Quicksilver Accesories Guide 2019

STEERING

MECHANICAL TILLER WITHOUT P/S THROTTLE AND SHIFT KIT- 35 AND 40 JET
FOURSTROKE BIG TILLER

8M0143358
The kit includes 2 ‑ T/S cables. These cables are designed to provide best in class
installation for this engine family.
The kit is designed to work with the 35 and 40HP Jet FourStroke engines with Big
Tiller.
THROTTLE AND SHIFT KIT- 75-115 FOURSTROKE
8M0093581 TILLER
The Big Tiller is designed for optimal performance and ergonomic comfort. With 8M0083500
improved friction adjustments, easy access to the throttle and shift handle and a The kit includes 2 ‑ T/S cables. These cables are designed to provide best in class
trim button at the end of the handle the Big Tiller provides safe and effortless installation for this engine family.
operation. The kit is designed to work with the 2.1L 75‑115 HP FourStroke engines. (Upgrade
with no spacer Ref Tiller Arm 8M0093581).
The RPM Adjustment (Troll Control) and LED light switch are optional on this
model. THROTTLE AND SHIFT KIT- 75-115 1.5L OPTIMAX
TILLER
Tiller is 3 inches shorter than previous model p/n 8M0074795.
Power Steering is strongly recommended for 75‑115 HP 1.5L OptiMax
MECHANICAL TILLER WITHOUT P/S

8M0083238
The kit includes 2 ‑ T/S cables. These cables are designed to provide the best in
class installation for this engine family.
The kit is designed to work with the 75 ‑ 115 HP OptiMax engines. (Upgrade with
879291A04 no spacer Ref Tiller Arm 8M0093581).
The Big Tiller is designed for optimal performance and ergonomic comfort. With THROTTLE AND SHIFT KIT- 135-250 OPTIMAX
improved friction adjustments, easy access to the throttle and shift handle and a
trim button at the end of the handle the Big Tiller provides safe and effortless
operation.
The RPM Adjustment (Troll Control) and LED light are optional on this model.
T/S kit 40 ‑ 60 HP not included
40‑60 HP FourStroke used with ELPT generation change S/N 1C050252 and
above.
MECHANICAL TILLER WITHOUT P/S

8M0082353
The kit includes 2 ‑ T/S cables. These cables are designed to provide the best in
class installation for this engine family.
The kit is designed to work with the 135 ‑ 250 HP OptiMax engines.

879291A05
The Big Tiller is designed for optimal performance and ergonomic comfort. With
improved friction adjustments, easy access to the throttle and shift handle and a
trim button at the end of the handle the Big Tiller provides safe and effortless
operation.
The RPM Adjustment (Troll Control) and LED light switch are optional on this
model.
This is a conversion kit that allows installation of the Big Tiller on a current tiller STEERING
handle model ELHPT 40 ‑ 60 HP FourStroke with generation change S/N
1C050252 and above.
T/S kit 40 ‑ 60 HP is not included.

Not all parts listed are available for the European, C.I.S., Africa and Middle East Markets. 629
For more information, please contact your local Mercury, Mariner, MerCruiser or
Quicksilver Office.
