STEERING

8M0134636 POWER STEERING COMPONENTS
This Power Steering Triple Rigging Kit includes 1 50 CM3 Tilt Helm, 3 Signal
harnesses 30 ft. connect each engine to Power Module, 1 Power Module with 12 ft.
leads, Automatic Power Switch and a Triple Engine Power Module Adapter to HELM - POWER STEERING - STANDARD
connect the signal wires (Use when the power module and the batteries are
mounted under the console). Hose kits ordered separately. When using 50 amp
fuse product you will need to order a Fuse/Harness Assembly when installing more
than one battery.
Multiple Engine 150 FourStrokes and Optimax (No Single engines), Verado
135‑200 4 Cylinder, 200‑350 HP Verado, 350 SCI and 400R.
POWER STEERING TILT RIGGING KIT
8M0134637
This Power Steering Triple Rigging Kit includes 1 50 CM3 Tilt Helm, 3 Signal
harnesses 30 ft. connects each engine to Power Module, 1 Power Module with 24
ft. leads, Automatic Power Switch and a Triple Engine Power Module Adapter to
connect the signal wires (Use when the power module is mounted in the back and
the batteries are mounted under the console). Hose kits ordered separately. When
using 50 amp fuse product you will need to order a Fuse/Harness Assembly when 8M0137445
installing more than one battery. Power Steering helm with a fixed position mount. Includes cover, bracket and
Multiple Engine 150 FourStrokes and Optimax (No Single engines), Verado mounting hardware. (40 CM3) 4.1 turns lock to lock with one cylinder
135‑200 4 Cylinder, 200‑350 HP Verado, 350 SCI and 400R. Multiple Engine 150 4 strokes and Optimax (No Single engines) , Verado 135‑200
4 cylinder, 200‑300 Verado 6 cylinder, 350 SCI
POWER STEERING - QUAD HELM - POWER STEERING -TILT

POWER STEERING RIGGING KIT

8M0137447
Power Steering Helm 40 CM3 Tilt. Includes all brackets and hardware needed to
8M0134641 install helm.
This Power Steering Quad Rigging Kit includes 1 50 CM3 Tilt Helm, 4 Signal Provides 4.1 turns lock to lock with one cylinder
harnesses 30 ft. connect each engine to Power Module, 1 Power Module with 4 ft. Multiple Engine 150 4 strokes and Optimax (No Single engines) , Verado 135‑200
leads, 2 each Automatic Power Switch and a Quad Engine Power Module Adapter 4 cylinder, 200‑300 Verado 6 cylinder, 350 SCI
to connect the signal wires (Use when the power module and the batteries are
mounted under the console). Hose kits ordered separately. When using 50 amp HELM - POWER STEERING - STANDARD
fuse product you will need to order a Fuse/Harness Assembly when installing more
than one battery.
Multiple Engine 150 FourStrokes and Optimax (No Single engines), Verado
135‑200 4 Cylinder, 200‑350 HP Verado, 350 SCI and 400R.
POWER STEERING RIGGING KIT- QUAD
8M0134639
This Power Steering Quad Rigging Kit includes 1 50 CM3 Tilt Helm, 4 Signal
harnesses 30 ft. connect each engine to Power Module, 1 Power Module with 12 ft.
leads, 2 each Automatic Power Switch and a Quad Engine Power Module Adapter
to connect the signal wires (Use when the power module and the batteries are
mounted under the console). Hose kits ordered separately. When using 50 amp
fuse product you will need to order a Fuse/Harness Assembly when installing more
than one battery. 892558A02
Multiple Engine 150 FourStrokes and Optimax (No Single engines), Verado
135‑200 4 Cylinder, 200‑350 HP Verado, 350 SCI and 400R. Power Steering helm with a fixed position mount. Includes cover, bracket and
mounting hardware.(50 CM3) Use with dual cylinder applications such as triple/
POWER STEERING RIGGING KIT quad engine installations. (6.5 turns lock to lock with two cylinders)
8M0134640 Multiple Engine 150 4 strokes and Optimax (No Single engines), Verado 135‑200 4
This Power Steering Quad Rigging Kit includes 1 50 CM3 Tilt Helm, 4 Signal cylinder, 200‑300 Verado 6 cylinder, 350 SCI
harnesses 30 ft. connects each engine to Power Module, 1 Power Module with 24
ft. leads, 2 Automatic Power Switch and a Quad Engine Power Module Adapter to
connect the signal wires (Use when the power module is mounted in the back and
the batteries are mounted under the console). Hose kits ordered separately. When
using 50 amp fuse product you will need to order a Fuse/Harness Assembly when
installing more than one battery.
Multiple Engine 150 FourStrokes and Optimax (No Single engines), Verado
135‑200 4 Cylinder, 200‑350 HP Verado, 350 SCI and 400R. STEERING
