STEERING

8M0134650 POWER STEERING - TRIPLE
Complete Power Steering Dual Rigging Kit that includes the Power Steering
Module (24 ft. lead), Tilt 40 CM3 Helm, Dual engine adapter harness, Automatic
Power switch and two engine signal harnesses 20 ft. in length. Hoses need to be POWER STEERING 50 CM3 RIGGING KIT
ordered separately Cylinder to Helm kit and Power Module to Helm Kit. When
using 50 amp fuse product you will need to order a Fuse/Harness Assembly when
installing more than one battery.
Multiple Engine 150 FourStrokes and Optimax (No Single engines), Verado
135‑200 4 Cylinder and 200‑300 HP Verado.
STEERING KIT 50 CC TILT HELM

8M0134644
This Power Steering Triple Rigging Kit includes 1 50 CM3 Std Helm, 3 Signal
harnesses 30 ft. connect each engine to Power Module, 1 Power Module with 4 ft.
battery leads, Automatic Power Switch and a Triple Engine Power Module Adapter
to connect the signal wires (Use when the power module and batteries are
mounted under the console). Hose kits ordered separately. When using 50 amp
fuse product you will need to order a Fuse/Harness Assembly when installing more
8M0135450 than one battery.
Complete Power Steering Dual Rigging Kit that includes the Power Steering Multiple Engine 150 FourStrokes and Optimax (No Single engines), Verado
Module (4 ft. lead), Tilt 50 CM3 Helm, Dual engine adapter harness, Automatic 135‑200 4 Cylinder, 200‑350 HP Verado, 350 SCI and 400R.
Power switch and two engine signal harnesses 30 ft. in length. Hoses need to be
ordered separately as well as cylinder to helm kit and Power Module to Helm Kit POWER STEERING RIGGING KIT
when using 50 amp fuse. You will need to order a Fuse/Harness Assembly when 8M0134642
installing more than one battery. This Power Steering Triple Rigging Kit includes 1 50 CM3 Std Helm, 3 Signal
Multiple Engine 150 FourStrokes and Optimax (No Single engines), Verado harnesses 30 ft. connect each engine to Power Module, 1 Power Module with 12 ft.
135‑200 4 Cylinder and 200‑400 HP Verado. 50CM3 is required for 350‑400hp. leads, Automatic Power Switch and a Triple Engine Power Module Adapter to
8M0135451 connect the signal wires (Use when the power module and batteries are mounted
Complete Power Steering Dual Rigging Kit that includes the Power Steering under the console). Hose kits ordered separately. When using 50 amp fuse product
you will need to order a Fuse/Harness Assembly when installing more than one
Module (12 ft. lead), Tilt 50 CM3 Helm, Dual engine adapter harness, Automatic battery.
Power switch and two engine signal harnesses 30 ft. in length. Hoses need to be
ordered separately as well as cylinder to helm kit and Power Module to Helm Kit
when using 50 amp fuse. You will need to order a Fuse/Harness Assembly when Multiple Engine 150 FourStrokes and Optimax (No Single engines), Verado
installing more than one battery. 135‑200 4 Cylinder, 200‑350 HP Verado, 350 SCI and 400R.
Multiple Engine 150 FourStrokes and Optimax (No Single engines), Verado
135‑200 4 Cylinder and 200‑400 HP Verado. 50CM3 is required for 350‑400hp. 8M0134643
This Power Steering Triple Rigging Kit includes 1 50 CM3 Std Helm, 3 Signal
STEERING KIT 50 CC TILT HELM harnesses 30 ft. connects each engine to Power Module, 1 Power Module with 24
ft. leads, Automatic Power Switch and a Triple Engine Power Module Adapter to
connect the signal wires (Use when the power module is mounted in the back and
the batteries are mounted under the console). Hose kits ordered separately. When
using 50 amp fuse product you will need to order a Fuse/Harness Assembly when
installing more than one battery.
Multiple Engine 150 FourStrokes and Optimax (No Single engines), Verado
135‑200 4 Cylinder, 200‑350 HP Verado, 350 SCI and 400R.
POWER STEERING RIGGING KIT

8M0135452
Complete Power Steering Dual Rigging Kit that includes the Power Steering
Module (24 ft. lead), Tilt 50 CM3 Helm, Dual engine adapter harness, Automatic
Power switch and two engine signal harnesses 30 ft. in length. Hoses need to be
ordered separately as well as cylinder to helm kit and Power Module to Helm Kit
when using 50 amp fuse. You will need to order a Fuse/Harness Assembly when
installing more than one battery.
Multiple Engine 150 FourStrokes and Optimax (No Single engines), Verado
135‑200 4 Cylinder and 200‑400 HP Verado. 50CM3 is required for 350‑400hp.
8M0134638
This Power Steering Triple Rigging Kit includes 1 50 CM3 Tilt Helm, 3 Signal
harnesses 30 ft long connect each engine to Power Module, 1 Power Module with
4 ft. leads, 2 each Automatic Power Switch and a Triple Engine Power Module
Adapter to connect the signal wires (Use when the power module and the batteries
are mounted under the console). Hose kits ordered separately. When using 50 amp
fuse product you will need to order a Fuse/Harness Assembly when installing more
STEERING Multiple Engine 150 FourStrokes and Optimax (No Single engines), Verado
than one battery.
135‑200 4 Cylinder, 200‑350 HP Verado, 350 SCI and 400R.
