INSTALLATION SPECIFICATIONS AND TOOLS

INSTALLATION SPECIFICATIONS AND TOOLS

INSTALLATION AIDS TRANSOM DRILLING FIXTURE - STANDARD
91-8M0149520
Only includes the drill fixture, standard 20 hole, 1" block.
14 PIN BRACKET
Fits: L4 and L6 Verado, 175‑300 HP V6 (3.4L) & V8 (4.6L), 150 HP FourStroke &
75‑115 HP (2.1L) EFI FourStroke engines.
DRILL GUIDE BLOCK - OEM 2 INCH
91-8M0149527
2‑Inch drill guide block with 2 holes
Profession option for OEM boat builders (utilize on new / undrilled transoms to
ensure thick transoms are drilled straight).
DRILL GUIDE BLOCK - 2 INCH
91-8M0149526
2‑Inch drill guide block with 5 holes
Professional option (use on thick transoms to ensure straight drill path).
8M0076435 DRILL GUIDE BLOCK - 1 INCH
Rounded edges and anti‑rotation 91-8M0149525
Rigging aid for 14 pin data cable 1‑Inch drill guide block with 5 holes.
NUT Standard option
TRANSOM DRILLING FIXTURE INSTALLATION SPECIFICATIONS AND TOOLS

11-889664
(1.500‑18) Black Nylon 91- 98234A 2
DUAL STATION RIG HARNESS Used to assist drilling of the holes for the outboard engine transom bracket
mounting bolts.
Mercury/Mariner 30/40 hp. & above (2 cycle), 25 hp. Bigfoot & above (4‑Stroke),
and Force 40‑150 hp (1993 and newer).
CONTROL DRILLING FIXTURE

91-8M0119480
Kit contains one harness and two weather caps
Used to temproarily rig a second station such that the vessel can be operated while
the second station is not installed (shipping, rigging installation, short term rework,
etc) 91-828363A 1
TRANSOM DRILLING FIXTURE KIT - PROFESSIONAL Used to assist drilling of the holes for side mount control and panel mount control
OPTION mounting bolts.
For use with the Commander 2000 side mount and the Commander 3000 panel
mount controls.

91-8M0138402
Kit includes: Suction cup for a seriously good hold for accurate drilling, suction cup
manual & cover, 2" drill guide blocks that ensure straight drill path for thick
transoms and 2 holes per guide block that reduces the likelihood of drilling into the
wrong hole.
Fits: L4 and L6 Verado, 175‑300 HP V6 (3.4L) & V8 (4.6L), 150 HP FourStroke &
75‑115 HP (2.1L) EFI FourStroke engines.
