INSTALLATION SPECIFICATIONS AND TOOLS

TRANSOM DRILL FIXTURE KIT ENGINE MOUNTING FIXTURE

91-866590A02 91-8M0114831
Used to assist drilling of the holes for the MerCruiser transom plate mounting bolts. Primary mount assembly. To be used in conjuction with Mount Fixture 22.5 in.(571
For MCM 1.6L Vazer models. mm) p/n 8M0114832 and/or Mount Fixture 25.2 in.(640 mm) p/n 8M0114833
For use with all Mercury high speed diesel engines
DRILL FIXTURE KIT ENGINE MOUNTING FIXTURE
INSTALLATION SPECIFICATIONS AND TOOLS Used to assist drilling of the holes for the MerCruiser transom plate mounting bolts. Fixture mount assembly. To be used in conjuction with Primary Mount Assemby p/n

91- 43693A 2
91-8M0114832
For MCM 3.0L to 350 Magnum (Alpha One), Bravo One, Two, Three and
8M0114831
Blackhawk models.
For use with all Mercury high speed diesel engines, except the V8 TDI
ENGINE MOUNTING FIXTURE
ENGINE MOUNTING FIXTURE

91-806794A02
Gasoline engine mount installation tool fixture. 91-8M0114833
MerCruiser gasoline engines, except Vazer engines. Fixture mount assembly. To be used in conjuction with Primary Mount Assemby p/n
91-807903A 1 8M0114831
For use with Mercury high speed V8 TDI diesel engines
Diesel engine mount installation tool fixture.
MerCruiser 2.8 ES (s/n 88010499 and below), D3.0 L, D3.6 L; D4.2 MS / ES (s/n ALIGNMENT SHAFT TOOL
88020199 and below)
ENGINE MOUNTING FIXTURE

91-805475A 1
Used to align the engine to the standard Bravo transom assembly for sterndrive
installation.
91-8M0084205
NLA ‑ Order 91‑8M0114831 plus 8M0114832 or 8M0114833 For MerCruiser drives, except Vazer drives.
Fits all QSD 2.0L, 2.8L & 4.2 engines
Also fits 1.7L, 2.8L & 4.2L (Tier 1) engines
