Page 778 - Quicksilver Accesories Guide 2019

MERCURY PROPELLER TYPE

HIGHFIVE PROPELLER MIRAGE PLUS PROPELLER MERCURY PROPELLER TYPE

48-815762A46 48- 18280A46
13 1/4 X 23 RH SS 5 BL 14 3/8 X 27 RH SS 3 BL
48-815760A46 48- 18281A46
13 1/4 X 21 RH SS 5 BL 14 3/8 X 27 LH SS 3 BL
48-815758A46 48- 13706A46
13 1/4 X 19 RH SS 5 BL 14 1/2 X 25 RH SS 3 BL
48-821154A46 48- 13704A46
13 1/2 X 17 RH SS 5 BL 14 5/8 X 23 RH SS 3 BL
48- 13705A46
MIRAGE PLUS 14 5/8 X 23 LH SS 3 BL
48- 13702A46
The Mirage Plus 3‑blade stainless steel propeller dominates 14 3/4 X 21 RH SS 3 BL
high‑horsepower boating with its large diameter and high output blade 48- 13703A46
geometry. From V‑6 Outboard offshore fishing boats to Bravo I 14 3/4 X 21 LH SS 3 BL
Sterndrive vee‑bottom sport boats, cruisers and race boats, the Mirage
Plus does it allquickly. 48- 13700A46
15.25 X 19 RH SS 3 BL
Equipped with Flo‑Torq II Hub kit 835257K1(A46) 48- 13701A46
15 1/4 X 19 LH SS 3 BL
‑The Flo‑Torq II SS (Solid) Hub kit 835258K 2 is available for separate 48-889620A46
purchase 15 3/8 X 18 RH SS 3 BL
‑The Flo‑Torq II 1 1/4" HD SS (Solid) Hub kit 840389K06 is available for
separate purchase 48-889619A46
For outboards over 150 HP on offshore fishing boats, Bay boats and 15 3/8 X 18 LH SS 3 BL
V‑bottom sportboats 48- 18278A46
15 1/2 X 17 RH SS 3 BL
For V‑8 single or dual Bravo One and TRS sterndrives
48- 90159A46
Specifically designed to handle high horsepower 15 1/2 X 17 LH SS 3 BL
48- 19838A46
Improves acceleration and top speed on many boats 15 3/4 X 15 RH SS 3 BL
48- 19841A46
Equipped with PVS ‑ Performance Vent System solid fittings installed
for outboard applications replace with medium fittings 15 3/4 X 15 LH SS 3 BL
48-826072A46
Left‑hand and right‑hand rotation 16 X 13 RH SS 3 BL
13" ‑ 27" pitch VENGEANCE

The Vengeance three‑blade stainless steel propeller is an excellent
choice for the boater who wants to upgrade from an aluminum prop.
The Mercury Vengeance is a fine propeller for outstanding durability and
good overall performance on most outboard and sterndrive powered
boats.
For all outboards and Alpha and Bravo One sterndrives
Better acceleration and handling than 3 blade aluminum
Over 5 times more durable than an aluminum prop
Proven blade design
L/H and R/H 9.5" ‑ 21" pitch
40‑60 HP are equipped with Flo‑Torq Reflex Hub System
40HP BigFoot and up are equipped with Flo‑Torq II Hub kit 835257K 1

Not all parts listed are available for the European, C.I.S., Africa and Middle East Markets. 771
For more information, please contact your local Mercury, Mariner, MerCruiser or
Quicksilver Office.
