HISTORICAL PROPELLER CHARTS

PART NO. DIAMETER PITCH MATERIAL BLADES ROTATION STATUS
27028A 2 N.L.A.
28765A 2 N.L.A.
29296A 2 N.L.A.
29958A 2 N.L.A.
29986A 2 N.L.A.

MERC 350/450/500/500SS
(11 SPLINE HUB, THRU HUB EXHAUST)
Thrust Hub 38859A1 Washer 12‑32007 Nut 11‑69578Q1

DIAMETER MATERIAL BLADES Style Quicksilver P/N OEM P/N
10-3/4 X 10 RH AL 3 Black Diamond N.L.A. N.L.A.

Merc 400/402/500/Merc 650/700 (3 Cyl)/Merc 35‑70
Merc 35‑70 (13 Spline Hub)
NLA = 48‑56228A1, 48‑56228A4, 48‑56230A1, 48‑56230A4, 48‑56250A1, 48‑56250A4, 48‑63452A1, 48‑63452A4, 48‑64726A1, 48‑64726A4
48‑63538A4, 48‑56232A4, 48‑56252A4, 48‑63454A4, 48‑63540A4, 48‑63546A1, 48‑63460A1, 48‑63548A1, 48‑63

PART NO. DIAMETER PITCH MATERIAL BLADES ROTATION STATUS OR
SUPERSESSION
73146A 4 10 19C AL 3 RH 73146A40
73146A40 10 19C AL 3 RH AVAIL.
64724A 1 & A 2 10-3/4 17 AL 3 RH 73144A40
64724A 4 10-3/4 17C AL 3 RH 73144A40
73144A 4 10 17C AL 3 RH 73144A40
73144A40 10 17C AL 3 RH AVAIL.
61824A 1 & A 2 10-3/4 16 AL 3 RH 73140A40
61824A 4 10-3/4 16C AL 3 RH 73144A40
63538A 1 10-3/4 16 BR 3 RH 73140A40
73142A 4 10 16C AL 3 RH 73142A40
73142A40 10 16C AL 3 RH AVAIL.
73138A40 10 16C AL 3 RH 91818A 5
91818A 4 10 16C SS 3 RH 91818A 5
73138A40 10 16C SS 3 RH AVAIL.
91818A 5 10 16C SS 3 RH AVAIL.
73138A40 10 16C SS 3 RH AVAIL. HISTORICAL PROPELLER CHARTS
56232A 1 10-3/4 15 AL 3 RH 73136A40
73136A40 10-3/4 15 AL 3 RH AVAIL.
56252A 1 10-3/4 15 BR 2 RH 73136A40
73136A40 10-3/4 15 BR 2 RH AVAIL.
63454A 1 10-3/4 15 BR 2 RH 73136A40
73136A40 10-3/4 15 BR 2 RH AVAIL.
63540A 1 11 15 BR 3 RH 73140A40
73140A 4 10-1/8 15 AL 3 RH 73140A40
73140A40 10-1/8 15C AL 3 RH AVAIL.
61822A 1 11 15 AL 3 RH 73140A40
61822A 4 11 15C AL 3 RH 73140A40
76232A 4 10-1/8 15C SS 3 RH 855862A 5
855862A 5 10-1/8 15C SS 3 RH AVAIL.
76232A5 10-1/8 15C SS 3 RH 855862A 5
855862A 5 10-1/8 15C SS 3 RH AVAIL.
61820A 1 &A 2 11-1/4 14 AL 3 RH 73138A40
61820A 4 11-1/4 14C AL 3 RH 73138A40
63542A 1 11-1/4 14 BR 3 RH 73138A40
63542A 4 11-1/4 14C BR 3 RH 73140A40

Not all parts listed are available for the European, C.I.S., Africa and Middle East Markets. 877
For more information, please contact your local Mercury, Mariner, MerCruiser or
Quicksilver Office.
