Page 920 - Quicksilver Accesories Guide 2019

PROPELLER HARDWARE AND ACCESSORIES

FLO-TORQ II HUB KIT EVINRUDE, JOHNSON AND OMC FLO-TORQ II HUB KIT YAMAHA

835271Q 2
8M0119082
835467 1 Forward thrust washer 853948 Forward thrust washer
879637 Plastic drive sleeve
879637 Plastic drive sleeve 826074Q1 Aft adapter
834899Q Aft adapter 850076 Spacer
8M0107489 Nut 859939 Nut
8M0118201 Washer Spacer 89961 Cotter Pin
89961 Cotter pin Yamaha 150‑300 HP HPDI 2‑stroke outboards using a one piece thrust washer
Evinrude/Johnson, OMC stern drives (V‑6 & V‑8 gearcase, 1984‑1990). Caution! and all Yamaha stern drives
When installing stainless steel propellers, remove the anode to bearing carrier and
check clearance before operation. Quicksilver Branded, Hanging Box Point of Sale Packaged.
Quicksilver Branded, Hanging Box Point of Sale Packaged. FLO-TORQ II HUB KIT YAMAHA
FLO-TORQ HUB KIT OMC COBRA / VOLVO SX

8M0075402
8M0119083 8M0064826 Forward thrust washer
835467 Forward thrust washer 879637 Plastic drive sleeve
826074Q1 Aft adapter
879637 Plastic drive sleeve 887972 Spacer
850330Q Aft adapter 859939 Nut
8M0107489 Nut 89961 Cotter Pin
89961 Cotter Pin
8M0118204 Washer Spacer 115‑250 HP VMAX SHO 4 stroke outboards using a two piece thrust washer.
OMC Cobra an Volvo SX stern drive 19‑tooth spline 1996 & Newer. Caution! Use part number 835274Q1 if OEM hub uses single piece thrust washer
When installing stainless steel propellers, remove the anode to bearing carrier and
check clearance before operation. Quicksilver Branded, Hanging Box Point of Sale Packaged.
Quicksilver Branded, Hanging Box Point of Sale Packaged.
FLO-TORQ II HUB KIT
FLO-TORQ II HUB KIT YAMAHA
835274Q 1
853948 1 Forward thrust washer
879637 Plastic drive sleeve
826074Q1 Aft adapter
887972 Spacer
859939 Nut
89961 Cotter Pin
150‑300 HP 4 stroke outboards and 115‑250 VMAX SHO outboards using OEM
single piece thrust washer
Use p/n 8M0075402 for 115‑250 VMAX SHO outboards using OEM two piece
thrust washer
Quicksilver Branded, Hanging Box Point of Sale Packaged.
835272Q 1
853555 Forward thrust washer
879637 Plastic drive sleeve
826074Q1 Aft adapter
850076 Spacer
859935 Nut
89961 Cotter Pin
Yamaha outboards (50‑100 HP, splined forward thrust washer)
Quicksilver Branded, Hanging Box Point of Sale Packaged. PROPELLER HARDWARE AND ACCESSORIES

Not all parts listed are available for the European, C.I.S., Africa and Middle East Markets. 913
For more information, please contact your local Mercury, Mariner, MerCruiser or
Quicksilver Office.
