Page 925 - Quicksilver Accesories Guide 2019

PROPELLER HARDWARE AND ACCESSORIES

DIFFUSER RING PROP NUT KIT

45676T 11-817752A 1
Mercury/Mariner V‑6, Alpha, Bravo I & TRS (current 43/4'' gearcase propellers) 820100 Prop nut
18‑45882 Cotter pin
DIFFUSER RING Force 4, 5, 7.5 & 15
PROP NUT KIT

54737T
MerCruiser Bravo II
11- 13914Q02
DIFFUSER RING 821932 1 Thrust washer, 23‑42091 1 Spacer, 11‑40140 Prop nut
Mercury/Mariner 6‑15 HP 2‑cycle, 9.9 hp FourStroke (1994‑2004), 15 hp
FourStroke (1994‑2006), Force 9.9/15 hp 2‑cycle 1998 & newer.
Priced individually, sold @ multiples of 2
Quicksilver Branded, Clamshell Package Point of Sale Packaged.
PROP NUT KIT

42594T
OMC 9.9 ‑ 15 HP
PROP NUT KITS

PROP NUT KIT 13914Q03
Prop nut, thrust hub, cotter pin & washer
Fits the Mercury/Mariner 25 & 30 hp. EFI FourStroke outboards beginning with
MY2006.
Priced individually, sold @ multiples of 2

PROPELLER HARDWARE AND ACCESSORIES 819883 Prop nut 2019 Quicksilver Precision Parts & Accessories Guide

FA94094-2
18‑89961 Cotter pin
25‑20195 O‑Ring
Force 30, 40, 50

918
