Page 930 - Quicksilver Accesories Guide 2019

PROPELLER HARDWARE AND ACCESSORIES

PROP NUT SHEAR PIN

11-826711 27 17-815111Q02
12‑39817 Prop washer Fits the Mercury/Mariner/Force 2/2.5/3/3.3hp 2‑cycle and 2/2.5/3.5hp FourStroke
For use with Bravo II and Mercury Racing Six Drive outboards. Visit the prop charts or parts catalogs for proper matching selections.
Priced individually, sold @ multiples of 2
PROP NUT Quicksilver Branded, Clamshell Package Point of Sale Packaged.

COTTER PINS
COTTER PIN

859929
OMC 40‑140 HP V‑4 (OEM P/N 314053)
PROP NUT

18- 89961
1/8" X 1‑1/4"
Force 30, 40, 50
COTTER PIN

859939
Suzuki DT 40‑65, 75‑115 HP V‑4, V‑6 (OEM P/N 09141‑18005), Yamaha V‑4 &
V‑6 (OEM P/N 90171‑18M04‑00), Honda 75‑115 & FS200‑225 HP (OEM P/N
90301‑ZW1‑B00)
SHEAR PINS
18-815026
SHEAR PIN KIT Fits Mariner 9.9C (682) 15C (684), and fits Mercury/Mariner 8/9.9 hp. FourStroke
standard gearcase outboards (Model Year 2005 & newer).
Priced individually, sold @ multiples of 5
COTTER PIN

FA324101
17‑820150 Shear Pin (3)18‑45882 Cotter Pin
Force 4‑15 HP PROPELLER HARDWARE AND ACCESSORIES
18- 95295
Thruster (R, RL, RX, T series) Mariner 30 (689B)
Priced individually, sold @ multiples of 5

Not all parts listed are available for the European, C.I.S., Africa and Middle East Markets. 923
For more information, please contact your local Mercury, Mariner, MerCruiser or
Quicksilver Office.
