Page 926 - Quicksilver Accesories Guide 2019

PROPELLER HARDWARE AND ACCESSORIES

PROP NUT KIT PROP NUT KIT

803743Q01 11- 40119Q02
803743 THRUST HOLDER 858498 Front thrust washer, 11‑40119 12 Prop nut
12‑16140 2 WASHER Mercury/Mariner 18‑25 HP (1980 to present)
11‑16147 1 PROP NUT
18‑815026 4 COTTER PIN Priced individually, sold @ multiples of 2
Fits the Mercury / Mariner 9.9 HP BF FS/ Pro Kicker, 15/20 HP FS (9.9 Big Foot Quicksilver Branded, Clamshell Package Point of Sale Packaged.
Model Year 2005 and Newer) (15/20 HP FS 2007 and Newer). PROP NUT KIT
Priced individually, sold @ multiples of 2
PROP NUT KIT

11- 69578Q 1
Kit includes a special locking nut and two tab washers.
803743Q02 For use on Mercury/Mariner 30‑60 hp. outboard engines.
8M0070811 THRUST HOLDER Priced individually, sold @ multiples of 2
12‑16146 WASHER Quicksilver Branded, Clamshell Package Point of Sale Packaged.
11‑16147 PROP NUT
18‑815026 1 COTTER PIN HARDWARE KIT
Mercury / Mariner 8/9.9 HP FS, (Model Year 2005 and Newer)
Priced individually, sold @ multiples of 2
PROP NUT KIT

8M0088039
Adapts 40‑60 HP Black Diamond, Nemesis, and Silverado propellers with Flo‑Torq
Reflex Hubs to fit Suzuki 35‑65 HP engines. Kit contains both forward and aft
washers.
11- 64075A 1
23‑65439 Spacer HARDWARE KIT
12‑79552 Washer
11‑34933 Prop nut
Mercury/Mariner 200 (old 20 HP)

8M0053074 PROPELLER HARDWARE AND ACCESSORIES
Adapts Mercury 30‑60 HP Black Max, Trophy Sport & Vengeance propellers with
Flo‑Torq Reflex Hubs to fit Tohatsu 40‑50 HP engines. Kit contains both forward
and aft washers.

Not all parts listed are available for the European, C.I.S., Africa and Middle East Markets. 919
For more information, please contact your local Mercury, Mariner, MerCruiser or
Quicksilver Office.
