Page 921 - Quicksilver Accesories Guide 2019

PROPELLER HARDWARE AND ACCESSORIES

DRIVE SLEEVE HUB ASSEMBLY WITH SLEEVE

835290Q 1 850821Q12
Plastic drive sleeve Flo‑Torq II Short, (3 5/8") with bushing (849501‑1), included in steel hub kits
Quicksilver Branded, Hanging Box Point of Sale Packaged. Stainless steel drive sleeve for A46/A47/A56 P/N suffix (400 HP+). Standard length
hub for use with Tempest Plus, Mirage Plus, REV 4, Trophy Plus, Bravo I &
DRIVE SLEEVE Maximus propellers (Bravo One Sterndrive 400HP+, 1" prop shaft). Used with
Mercury and selected Yamaha propshafts.
Quicksilver Branded, Hanging Box Point of Sale Packaged.
AFT ADAPTER WITH TAB WASHER

881940Q 1
Flo‑Torq III Spring Drive Sleeve
For use with 40 ‑ 60 BigFoot, 75 ‑ 115 HP FourStroke outboards (Reduce prop
rattle)
826074Q 1
DRIVE SLEEVE Adapter for use with Flo‑Torq II plastic Drive Sleeve (15 Spline)
Kit contains: 8M0042201 (aft adapter) & 8M0042130 (tab washer)
Mercury 40 BigFoot ‑ 250 HP outboards & MerCruiser Alpha and Bravo One
Sterndrives, Honda 75 ‑ 225 HP, Suzuki 90 ‑ 140 4‑stroke & 150 ‑ 225 HP,
Tohatsu/Nissan 40 ‑ 140 HP, Yamaha 50 ‑ 225 HP outboards (1" prop shaft).
Quicksilver Branded, Hanging Box Point of Sale Packaged.
AFT ADAPTER WITH TAB WASHER

896233A01
Flo‑Torq IV Spring Drive Sleeve
For use with Verado L4SC 135‑175 HP (Aluminum or Stainless steel props,
reduces prop rattle).
HUB ASSEMBLY WITH SLEEVE
8M0061986
Kit contains 8M0115120 (aft adapter) & 8M0042130 (tab washer)
Drive sleeve for use with Flo‑Torq III and IV. (15 Spline) Includes pin style tab
washer

PROPELLER HARDWARE AND ACCESSORIES Long, (3 7/8") with bushing (849501‑1), included in steel hub kits 2019 Quicksilver Precision Parts & Accessories Guide

850821Q11
Stainless steel drive sleeve for A45/A55 P/N suffix (400 HP+) for use with Chopper,
Cleaver, Lightning ET, Pro ET & Bravo I (with MerCruiser logo) propellers. Used
with Mercury and selected Yamaha propshafts.
Quicksilver Branded, Hanging Box Point of Sale Packaged.

914
