HOOKS

Chain Link

For easy connection of anchor rope thimbles to anchor chain. Available in rugged stainless steel or zinc-plated steel
construction material.

Maximum Bulk Prop Aftermarket Prop
Description Diameter Length Safe Load Packaging 65 Packaging 65
Stainless Steel 5/16" 2-7/8" 3,000 lbs. — 12891L3
3/8" 3-1/4" 4,000 lbs. — 12889L3
Zinc-Plated Steel 7/32" 2-1/4" 1,000 lbs. — 12355-3
5/16" 3" 2,000 lbs. — 12357-3

Marine Carabiner 12891

Spring-loaded closure.

Ring Maximum Bulk Prop Aftermarket Prop
Description Length Diameter Safe Load Packaging 65 Packaging 65
Stainless Steel 2-1/2" 1/4" 350 lbs. 12412-1 —
3-1/8" 5/16" 575 lbs. — 12415L3
Zinc-Plated Steel 2-1/2" 1/4" 300 lbs. — 12303-3
3-1/2" 3/8" 600 lbs. — 12305-3
3-1/8" 5/16" 700 lbs. — 7651-3

Utility Snap Hook 12415

Zinc-plated steel with spring-loaded closures.
7653 7640
Maximum Bulk Aftermarket
Description Length Ring Diameter Safe Load Packaging Packaging
Light-duty 4" 1/4" 500 lbs. — 7653L3
Heavy-duty 4" 5/8" 2,500 lbs. — 7640-3
Heavy-duty 4-1/4" 5/8" 2,500 lbs. — 12261L3

12261

Maximum safe load is approximately half of maximum load or break strength.
Do not exceed maximum safe load. Do not use in applications where life or limb is at risk.
