Threaded Studs

SL68-BS SL69-BS SL70-BS SL64-BS SL74SSBS
Used as an alternative to mounting brackets, threaded studs can be mounted directly to hatches or other mounting
surfaces in applications where the mounting surface is made of metal or another material with the strength to
withstand the forces of a gas spring attachment point
Choice of Attachment Points and Finish
Threaded studs are available with “Ball” or “Blade” gas spring attachment points, and a choice of materials, including
zinc plated steel, or stainless steel.

Bulk Prop Aftermarket Prop
Finish Length Packaging 65 Packaging 65
WITH 10MM BALL END
Zinc Plated 3/8" SL68-BS-1 —
9/16" SL69-BS-1 —
SL68BS
1" SL70-BS-1 —
Stainless Steel 3/4" SL75-SSBS-1 —
9/16" SL69SSBS-1 —
WITH 13MM BALL END
Zinc Plated 19/32" SL64-BS-1 —
Stainless Steel 19/32" SL64SSBS-1 —
SL70BS
1" SL74SSBS-1 —
MOUNTING BRACKETS SL64SSBS

Mounting Brackets are used as attachment points for gas springs on hatches and other mounting surfaces where:
• Mounting surface material is not strong enough to support direct attachment of gas spring using a threaded stud
• The angle and position of the attachment point requires the need for a mounting bracket
Choice of Pem Attachment Ball Pem Points and Finish
Mounting brackets are available with Blade Pem or Ball Pem gas spring attachment points, and a choice of materials and
finishes, including zinc-plated steel (with or without black painted finish), stainless steel, or aluminum.

Aftermarket Mounting Brackets

Bracket Mounting Aftermarket Prop
Series No. Style Pem Type Holes Pem Direction Finish Packaging 65
SL40 Flat Ball 10mm 2 Forward Stainless Steel SL40SSP3-7
SL50 90° Ball 10mm 2 Forward Stainless Steel SL50SSP3-7
