Product Category Fast Gaming
ROG Swift PG349Q ROG Swift PG348Q ROG Swift PG32UQX

Motherboards
Motherboards
Panel Size (diagonal) 34.14" (86.72cm) Wide Screen (21:9) 34" (86.72cm) Wdie Screen (21:9) 32" Wide Screen (16:9)
Viewing Area (HxV) 799.8 x 334.8mm 819.3 x 363.0mm 708.48 x 398.52 mm
Panel Backlight WLED WLED Mini-LED
Panel Type IPS IPS IPS
Display Surface Non-glare Non-glare Non-glare
Curvature 1900R 3800R --
Color Saturation 100% sRGB 100% sRGB 98% DCI-P3
True Resolution 3440 x 1440 3440 x 1440 3840 x 2160
Refresh Rate (Max.) 120Hz 100Hz 144Hz
Pixel Pitch (mm) 0.2325mm 0.2325mm (109 ppi) 0.185 mm
Brightness 300cd/㎡ 300cd/㎡ 1000 cd/m²
Display
Contrast Ratio (Max.) 1,000:1 1,000:1 1,000:1
Viewing Angle (CR≧10) 178°(H)/178°(V) 178°(H)/178°(V) 178°(H) / 178°(V)
Display Colors 1.07B 1.07B 1.07B
Graphics Cards & PSUS
Graphics Cards & PSUS
Response Time 4ms (Gray to Gray) 5ms (Gray to Gray) 4ms (Gray to Gray)
Dynamically Local Dimming -- -- Yes
Flicker-free Yes Yes Yes
HDR support -- -- Yes
HDR Certificate -- -- DisplayHDR 1400
Low Blue Light Yes Yes Yes
Trace Free Technology Yes Yes Yes
SPLENDID™ (Mode) -- -- --
GameVisual (Mode) Yes Yes Yes
Display
Display
Skin-Tone Selection -- -- --
Color Temperature Selection Yes Yes Yes
HDCP Yes Yes Yes
3D Technology -- -- --
Color Accuracy -- -- --
Gamma adjustment -- -- --
Video QuickFit (modes) -- -- --
Features Ambient Light Sensor -- -- --
Picture-in-Picture/ Picture-by-Picture -- -- --
Networks
Networks
GamePlus Yes Yes Yes
VRR Technology NVIDIA G-SYNC NVIDIA G-SYNC NVIDIA G-SYNC
Extreme Low Motion Blur -- -- --
Extreme Low Motion Blur Sync -- -- --
DisplayWidget -- -- --
Shadow Boost -- -- --
Game Fast Input technology -- -- --
Stereo Speaker 2W x 2 stereo, RMS 2W x 2 stereo, RMS --
Audio Tech. -- -- --
Audio
Features Audio Mode -- -- --
ODD & Storage
ODD & Storage
Signal Input DisplayPort, HDMI DisplayPort, HDMI DisplayPort, HDMI
Input/ Output PC Audio Input -- -- --
Earphone Jack Yes Yes Yes
USB port(s) USB 3.0 USB 3.0 USB 3.0
(Upstream x 1, Downstream x 2) (Upstream x 1, Downstream x 4) (Upstream x 1, Downstream x 1)
Power Consumption** <85W (1) <100W (1) <58.47W (1)
Power Saving Mode <0.5W <0.5W <0.5W
Power
Power Off Mode <0.5W <0.5W <0.3W
Voltage 100–240V, 50/ 60 Hz 100–240V, 50/ 60 Hz 100–240V, 50 / 60 Hz
Tilt (angle) +20° ~ -5° +20° ~ -5° +20° ~ -5°
Swivel (angle) +50° ~ -50° +50° ~ -50° +20°~ -20°
Server & Workstation
Server & Workstation
Pivot (angle/direction) -- -- --
Mechanical Height Adjustment (mm) Yes (0~100mm) Yes (0~100mm) Yes(0~80 mm)
Design
VESA Wall Mounting (mm) 100 x 100mm 100 x 100mm 100 x 100 mm
Stand Lighting LED Lighting projection LED Lighting projection --
Lighting effect -- -- Yes(Aura RGB)
Security Kensington lock Yes Yes Yes
Phys. Dimension with Stand (WxHxD) 815.85 x 560.22 x 307.59mm 829 x 558 x 297mm 727 x (504~574) x 306mm
Dimension Phys. Dimension without Stand (WxHxD) 815.85 x 560.22x128.55mm 829 x 323 x 109mm 727 x 441 x 95mm
Box Dimension (WxHxD) 956 x 577 x 293mm 320 x 508 x 942mm 863 x 610 x 284mm
Net Weight (Esti.) 9.9kg 11.2kg 7.6kg
Mini / Stick PC
Mini / Stick PC
Weight Net Weight without Stand 6.6kg 7.7kg 10.9kg
Gross Weight (Esti.) 15kg 15.5kg 17.3kg
NVIDIA G-SYNC -- G Sync Ultimate, TUV Flicker
Technology, TUV-Flicker Free, TUV Low Blue Light,
Free technology, TUV-Blue DisplayHDR 1400
Special Features Peripherals Light Filter, ASUS Aura
Sync technology,
ROG lighting projection
Peripherals
(1)Measuring a screen brightness of 200 nits without audio/ USB/ Card reader connection | (2)Depends on region
