Product Category Fast Gaming
ROG Swift PG65UQ ROG Swift PG43UQ ROG Swift PG35VQ Motherboards

Motherboards
Panel Size (diagonal) 64.53" (163.9cm) Wide Screen (16:9) 42.5" (107.99cm) 35" (88.9cm) Wdie Screen (21:9)
Viewing Area (HxV) 1428.48 x 803.52mm 941.184 x 529.416mm 819.4 x 345.9mm
Panel Backlight Direct Type (384 zones) WLED WLED direct type LED (512 zones)
Panel Type VA VA VA
Display Surface Non-glare Non-glare Non-glare
Curvature -- -- 1800R
Color Saturation 90% DCI-P3 125% sRGB 90% DCI-P3
True Resolution 3840 x 2160 3840 x 2160 3440 x 1440
Refresh Rate (Max.) 144Hz (OC) 144hz 200Hz
Pixel Pitch (mm) 0.372 mm 0.2451mm Graphics Cards & PSUS 0.238mm (106ppi) Graphics Cards & PSUS
Brightness 750cd/㎡ (typical/HDR on) 750cd/㎡ 300cd/㎡ (typical/SDR on)
Display
1,000cd/㎡ (peak/HDR on) 600cd/㎡ (typical/HDR on)
1,000cd/㎡ (peak/HDR on)
Contrast Ratio (Max.) 4,000:1 4,000:1 2,500:1
Viewing Angle (CR≧10) 178°(H)/178°(V) 178°(H)/178°(V) 178°(H)/178°(V)
Display Colors 16.7M 1.07B 16.7M
Response Time 4ms (Gray to Gray) 1ms MPRT 4ms (Gray to Gray)
Dynamically Local Dimming Yes Yes --
Flicker-free Yes Yes Yes
HDR support Yes Yes Yes
HDR Certificate Display HDR1000/ UHDA Display HDR1000 DisplayHDR 1000
Low Blue Light Yes Yes Yes
Trace Free Technology -- Yes Display Yes Display
SPLENDID™ (Mode) -- -- --
GameVisual (Mode) Yes Yes Yes
Skin-Tone Selection -- -- --
Color Temperature Selection Yes Yes Yes
HDCP Yes Yes Yes
3D Technology -- -- --
Color Accuracy △E< 2 △E< 2 △E< 2
Gamma adjustment Yes (1.8/ 2.0/ 2.2/ 2.4/ 2.6) Yes (1.8/ 2.2/ 2.5) Networks -- Networks
Video QuickFit (modes) -- -- --
Features Ambient Light Sensor Yes -- Yes
Picture-in-Picture/ Picture-by-Picture -- PBP --
GamePlus Yes Yes Yes
VRR Technology Gsync FreeSync2HDR NVIDIA G-SYNC HDR
Extreme Low Motion Blur -- Yes --
Extreme Low Motion Blur Sync -- -- --
DisplayWidget -- Yes --
Shadow Boost -- Yes --
Game Fast Input technology -- Yes --
Stereo Speaker 15W x 2 stereo, RMS 10W x 2 stereo, RMS ODD & Storage -- ODD & Storage
Audio Tech. Audio Output SonicMaster --
Audio (Internal Speaker/ SPDIF)
Features Audio Mode AudioWizard AudioWizard --
(OFF/ Gamming/
Movie (Default) mode)
Signal Input DisplayPort, HDMI2.0 x 4 HDMI (v2.0) x 2, DisplayPort 1.4, HDMI (v2.0)
DisplayPort (v1.4) x 2
Input/ Output PC Audio Input -- -- --
Earphone Jack -- Yes Yes
USB port(s) -- USB 3.0 Downstream x 2 USB 3.0
(Upstream x 1, Downstream x 2) Server & Workstation
Power Consumption** <700W <48W (1) 66W (1)
Power Saving Mode <0.5W <0.5W <0.5W
Power
Power Off Mode <0.5W <0.5W <0.5W
Voltage 100–240V, 50/ 60 Hz TBD 100–240V, 50/ 60 Hz
Tilt (angle) -- +10° ~ -5° +21° ~ -6°
Swivel (angle) -- -- +35° ~ -35°
Server & Workstation
Pivot (angle/direction) -- -- --
Mechanical Height Adjustment (mm) -- -- Yes (0~110mm)
Design
VESA Wall Mounting (mm) 400 x 400mm 100 x 100mm 100 x 100mm
Stand Lighting -- LED Lighting projection LED Lighting projection
Lighting effect -- Yes Yes
Security Kensington lock Yes Yes Mini / Stick PC Yes Mini / Stick PC
Phys. Dimension with Stand (WxHxD) 1448.08 x 946.9 x 389.82mm 974.58 x 631.31 x242.19mm 833 x 549 x 306mm
Dimension Phys. Dimension without Stand (WxHxD) 1448.08 x 863.83 x 87.2mm 974.58 x 570.62 x 74.6mm 833 x 380 x 150mm
Box Dimension (WxHxD) 1630 x 1104 x 507mm 1069 x 722 x 295mm 986 x 587 x 322mm
Net Weight (Esti.) 36.8kg 15.3kg 10.5kg
Weight Net Weight without Stand 32.76kg 14.2kg 13.6kg
Gross Weight (Esti.) 57.5Kg 22.8kg 20.4kg
Gsync Ultimate, AMD FreeSync2HDR, Hi-Fi grade ESS ES9118
TUV-Flicker, Free DisplayWidget, TUV-Flicker amp built-in. (Sampling rate
technology, TUV-Blue Light Free technology, TUV-Blue 24bit/192KHz)
Special Features Filter, LED (patent risk free), Light Filter LED (patent risk Peripherals Peripherals
DisplayHDR1000,UHDA free)
certified, AURA SYNC
(1)Measuring a screen brightness of 200 nits without audio/ USB/ Card reader connection | (2)Depends on region
