Internal extractor set Triple pliers
With titanium nitride-plated surface, extra hard and non- Flat, stripping, and crimping pliers.
wearing. Dip-coated grips.
For close-lying ball bearings, rings, bushings, and Simmerrings ®.
High-quality, flexible material.
Improved transfer of forces due to absolutely exact manufacturing
precision.
Easy to use.
Higher spreading ranges.
Can be used with slide hammer or counter-support.
Attractive set composition.
Better heat-resistant surface protection due to harder,
non-wearing titanium nitride-plated surface.
Application:
Insert the internal extractor lengthwise and screw in the spindle.
Sharp shell lugs press in behind the part to be extracted.
Put the slide hammer or counter-support into place.

K Art. No. P. Qty.
160 1952 000 172 1
Pliers for securing rings
For use in utility vehicles and construction and agricultural machines.
Toothed rack for maintaining the respective dismantling or installation
position.
Pressure mechanism for loosening the toothed rack.
Pliers arms made of sheet steel.
Tips hardened, screwed, and exchangeable.
Powder-coated surface.

K J % Art. No. P. Qty.

Straight, for internal securing mechanisms (boreholes)
545 3.5 122 - 300 1952 000 173 1
Content Art. No. P. Qty.
545 4.5 252 - 400 1952 000 174 1
5-part set in plastic box: Replacement tips, straight, for 1952 000 173 1952 000 175 1
4 internal extractors Conversion tips, angled by 90°,
5 to 8.5 / 8 to 15 / 15 to 24 / 25 to 36 mm for the conversion of the pliers 1952 000 173 1952 000 176 1
1 slide hammer with connecting thread M 10 Replacement tips, straight, for 1952 000 174 1952 000 177 1
1952 000 160 1 Conversion tips, angled by 90°,
Slide hammer with connecting thread M 10 for the conversion of the pliers 1952 000 174 1952 000 178 1
For extracting covers with internal threads, ball bearings, pulleys, etc.
In combination w/ threaded bolt set 1952 000 162 and internal extractor. Pliers for securing rings
10 1952 000 161 1 For use in utility vehicles and construction and agricultural machines.
Toothed rack for maintaining the respective dismantling or installation
Internal extractor 5 to 8.5 mm
position.
10 1952 000 165 1
Pressure mechanism for loosening the toothed rack.
Internal extractor 8 to 15 mm Pliers arms made of sheet steel.
Tips hardened, screwed, and exchangeable.
10 1952 000 872 1
Powder-coated surface.
Internal extractor 15 to 24 mm
10 1952 000 163 1
Internal extractor 25 to 36 mm
10 1952 000 164 1

MWF - 06/08 - 11516 - © • K J & Art. No. P. Qty.

Straight, for external securing mechanisms (shafts)
3.5
122 - 300
1952 000 180 1
538
Replacement tips, straight, for 1952 000 180
1952 000 179 1
16
