INSTALLATION

Fumex Wall Mount Adapter Installation Instructions

1. Locate top side of adapter for each size listed below.

(FX8, 11, 13, and 16 DIRECT DRIVE)

(ALL OTHER SIZES)

2. Install bolts threads up on top side. 3. Apply gasket to surface as shown.

INSTALL BOLTS FROM INSIDE ON TOP
ANGLE TO HANG WALL ADAPTER

SOME MODELS DO NOT
CONTAIN COOLING TUBE

DRAIN SPOUT FACES DOWN

4. Attach adapter securely to wall (Fasteners not 5. Hang fan from top bolts as shown; secure to
included. Depending on wall construction, this wall adapter with remaining bolts.
is to be attached at discretion of the installer.)

INSTALL BOLTS FROM INSIDE ON TOP
ANGLE TO HANG WALL ADAPTER

SOME MODELS DO NOT
CONTAIN COOLING TUBE

DRAIN SPOUT FACES DOWN
