ADVANTAGES

1. Various Design

TM
TM
TM
TM
TM
TM
TM
TM
TM
MODEL HM -5 HM -10 HM -15 HM -20 HM -27 HM -35 HM -54 HM -75 HM -N
Hydrogen
5 10 15 20 27 35 54 75 100~300
3
Production(Nm /h)**
Oxygen
2.5 5 7.5 10 13.5 17.5 27 37.5 50~150
3
Production(Nm /h)
3
3
3
3
3
3
3
3
3
Capacity. 5Nm /h 10Nm /h 15Nm /h 20Nm /h 27Nm /h 35Nm /h 27Nm /h 38Nm /h 50Nm /h
Cell
Stack
No. 1 set 1 set 1 set 1 set 1 set 1 set 2 sets 2 sets 2~6 sets
Delivery Pressure(bar) 3~10
** Can be tailored to meet your specific hydrogen requirements
2. Safety
m System designed for installation and operation in Class Ⅰ, Division 2, Group B area
m UPS ensuring a safe shutdown in case of power failure
m Measuring device for oxygen content in hydrogen stream(shutdown at 1% O 2 in H 2)
m Detection for hydrogen concentration in atmosphere(shutdown of the unit at 20%LEL)
3
m Minimal gas presence in the system during operation(only few Nm at full production)
3. Easy to use
m Fully automatic operation including continuous monitoring of all critical parameter for safe,
unattended operation
m Variable hydrogen production from 25~100% of capacity, ensuring quick automatic response to
process demand
m Easy to use graphical touch screen interface
m One touch start and stop functionality
m Oxygen gas is safely vented outside your facility
m Easily interlocked with facility instruments
m Remote monitoring and operations option
m Constant monitoring of gas purity

4. Proven Reliability

m Stringent quality control procedures and fully factory tested to exacting standards
m Highly efficiency using cell stack of zero-gap structure
m Durable stainless steel process components maximize system life over 20 years
m Low maintenance cost(limited moving parts)

TM
HM -Series Hydrogen Generators TEL : +82-31-451-6431, FAX : +82-31-451-6435
