112 | ChaPTer 4 Configuring TemplaTes and sTandards

Setting Line Patterns
Line patterns are created from a repetitive series of dashes, spaces, and dots. To edit or create line
patterns, switch to the Manage tab and choose Additional Settings ➢ Line Patterns. The Line
Patterns dialog box, shown in Figure 4.5, displays a list of existing line patterns in the project.

Figure 4.5
This dialog box
displays all line
patterns in the
project.

To edit an existing pattern, select a pattern from the list and then click the Edit button. Click
New to create your own patterns. You create and edit patterns by specifying dash and space
lengths, which will form a repeating sequence, as shown in Figure 4.6. For dots, a length value
isn’t required.

Figure 4.6
line patterns
consist of
dashes, spaces,
and dots.
