FLOWTECH SOLUTIONS LLP

40S series
The Codeline 40S series of standard 4” diameter, made
from filament wound epoxy/glass composites, is
applicable for operating pressures of 300 PSI, 450 PSI
and 600 PSI.

Unique benefits
1. End plug assembly: Single-piece head assembly for
non coded models with high-grade thermoplastic material
reduces the number of spares.
2. Integrally wound locking groove: enhanced end-margin
strength for better performance.
3. Membrane elements: Housing can accommodate a
maximum of six membrane elements.

80E series
The Codeline 80E series of standard 8” diameter and
made up of filament wound epoxy/glass composites is
applicable for operating pressure of 300 PSI, 450 PSI, 600
PSI, 1000 PSI and 1200 PSI.

Unique benefits
1. Quick locking mechanism: The user-friendly quick
lock system eliminates the need for special removal tools
and allows quick access to the membranes.
2. Integrally formed locking groove: enhanced end-
margin strength for better performance.
3. Construction: Superior material used for
feed/concentrate port for seawater applications.
80H series
The Codeline OCTA 80H series of standard 8” diameter
is applicable for operating pressure of 150 PSI, 300 PSI,
450 PSI, 600 PSI, 1000 PSI and 1200 PSI in brackish and
high brackish and sea water applications.

Unique benefits
1. Minimized leakage: The integrated octagonal shape
provides a flat surface for superior and reliable side port
sealing.
2. Improved head sealing: Integration into the
head/sealing plate provides better sealing and avoids head
seal roll, eliminating head leaks.
3. Integrally wound locking groove: enhanced end-margin
strength for better performance.
