376 Chapter 6 • Infrastructure Security: Devices and Media

To perform an attack using ARP spoofing, the intruder would follow this
procedure:

1. The intruder (I) sends an ARP packet to a client (C1) using the IP address
of another client (C2), but the MAC address for the intruder (I).
2. The intruder (I) sends an ARP packet to a client (C2) using the IP address
of another client (C1), but the MAC address for the intruder (I).
3. Now both clients have ARP cache entries for each other’s IP address, but
the MAC address for these entries point to the intruder.The intruder
routes packets between C1 and C2 so that communications are not inter-
rupted.

4. The intruder sniffs all packets it is routing and is able to see all communi-
cations between the clients.
This process allows intruders to view all traffic between two clients; however,
ARP spoofing can potentially be more damaging. By performing a MITM attack
between a router and the switch, an intruder can see all data coming through the
router.Additionally, if an intruder replies to every ARP request sent out by the
switch, it can intercept traffic going to all clients.This gives the intruder the option
of performing a DoS attack by not allowing any client to communicate with the
switch, not routing traffic to the intended client, and sniffing the data being com-
municated via the MITM attack.
Another vulnerability of most switches is that they can be configured by a stan-
dard Telnet session. If the network from which the Telnet session originated is
sniffed, passwords for the switch can be easily obtained, because they are sent in
cleartext. Some newer switches allow a secure session to be made for configuring
the switch.This secure session is made by using SSH instead of Telnet to connect to
the router.All communication between the client and the router is encrypted when
using SSH.Also, with both older and newer switches, configuration can be per-
formed via a console connection to the switch so that no configuration data goes
across the network.This is the most secure method of configuring switches, but
most network administrators find it inconvenient. SSH provides both security and
convenience on switches.

Wireless

Wireless technology is discussed in detail in Chapter 4 of this guide; however, based
on the Security+ exam objectives, devices related to wireless technology are also
