372 Chapter 6 • Infrastructure Security: Devices and Media

access-list <list_number> <permit/deny> <source_addresss> <mask>
For example, to create an “anti-spoof” set of rules (as discussed in
this section), the following rules can be used:
access-list 1 deny 207.46.230.0 0.0.0.255
access-list 2 allow 207.46.230.0 0.0.0.255

The first rule is applied to the wide area network (WAN) interface to
deny all traffic coming into that interface from an IP address belonging
to the internal network. The second rule is then applied to the internal
interface to allow all traffic coming into that interface from the internal
network addresses to pass through.

Most current routers offer security capabilities along with their routing func-
tionality. Segmenting a network using routers limits the amount of data flowing
between segments.Typically, this applies to broadcast traffic. Not propagating broad-
cast traffic between segments limits the amount of data that can be obtained from
them using a sniffer.The less information made available to a potential attacker the
better.
Routers also allow technicians to explicitly deny some packets the ability to be
forwarded between segments. For example, using just the internal security features
of some routers can prevent users on the internal network from using Telnet to
access external systems.Telnet is always a security risk, as the passwords and all
communications are transmitted in cleartext. Because of this, it is best not to create
Telnet sessions between the internal network and an external network.Without a
firewall, a rule can be put in place within the router to drop packets attempting to
connect to port 23 on any external system.All of this is done by properly config-
uring the ACLs for the router.An example rule for Cisco routers is as follows:
access-list 101 deny any any eq 23

Another useful security feature of routers is their ability to block spoofed
packets. Spoofed packets are packets that contain an IP address in the header that is
not the actual IP address of the originating computer.This technique is often used
by hackers to fool systems into thinking that the packet came from an authorized
system, when it actually originated at the hacker’s system. Routers combat this by
giving technicians the ability to drop packets coming through an interface from the
wrong subnet. For example, if a packet comes in from the router’s external inter-
face using an IP address from the network on the router’s internal interface, the
router can be instructed to drop the packet and not forward it. It should be noted
