426 Chapter 7 • Topologies and IDS

Introduction

In today’s network infrastructures, it is critical to know the fundamentals of basic
security infrastructure. Before any computer is connected to the Internet, planning
must occur to make sure the network is designed in a secure manner. Many of the
attacks that hackers use are successful because of an insecure network design.That
is why it is so important for a security professional to use the secure topologies and
tools like intrusion detection and prevention that are discussed in this chapter. For
example, if you are working with Cisco technologies (and other switch vendors),
you might be familiar with virtual local area network (VLAN) technology.VLANs
are responsible for securing a broadcast domain to a group of switch ports.This
relates directly to secure topologies, because different Internet Protocol (IP) subnets
can be put on different port groupings and separated, either by routing or by
applying an access control list (ACL) (e.g., the Executive group can be isolated
from the general user population on a network).
Other items related to topology that we examine in this chapter include demil-
itarized zones (DMZs). DMZ’s can be used in conjunction with network address
translation (NAT) and extranets to help build a more secure network.We’ll look at
each of these items and examine how they can be used to build a layered defense.

TEST DAY TIP

An ACL is a list of users that have permission to access a resource or
modify a file. ACLs are used in nearly all modern-day operating systems
(OSes) to determine what permissions a user has on a particular resource
or file.

The second half of this chapter covers intrusion detection. It is important to
understand not only the concepts of intrusion detection, but also the use and
placement of intrusion detection systems (IDSes) within a network infrastructure.
The placement of an IDS is critical to deployment success.This section also covers
intrusion prevention systems (IPS), honeypots, and incident response.
