Page 447 - StudyBook.pdf

Topologies and IDS • Chapter 7 431

make great choices for creating a “defense in depth” strategy, but remember that
the more work the firewall is doing to support these other functions, the more
chance there is that these additional tools may impact the throughput of the fire-
wall device.

Figure 7.3 A Sample Firewall Rule Set

Using a Defense-in-Depth Strategy
The defense-in-depth strategy specifies the use of multiple layers of net-
Head of the Class… measure deployed on your network. In other words, to eliminate the
work security. In this way, you avoid depending on one single protective

false feeling of security because you implemented a firewall on your
Internet connection, you should implement other security measures such
as an IDS, auditing, and biometrics for access control. You need many
levels of security (hence, defense in depth) to be able to feel safe from
potential threats. A possible defense-in-depth matrix with auditing
included could look like the graphic in Figure 7.4.

Figure 7.4 A Graphical Representation of Defense in Depth

Security Policy

Auditing and Access Control

Firewall
IDS System
