Topologies and IDS • Chapter 7 439

the protected network.To manage this situation, the firewall permits only systems
from the protected network to initiate connections with the financial segment.This
prevents an attacker from being able to directly access the protected network in the
event of a compromise. On the other hand, if the financial system must use real-
time transmissions or data from the computers on the protected network, the
financial systems have to be able to initiate those communications. In this event, if a
compromise occurs, the attacker can use the financial systems to attack the pro-
tected network through those same channels. It is always preferable that DMZ sys-
tems not initiate connections into more secure areas, but that systems with higher
security requirements initiate those network connections. Keep this in mind as you
design your network segments and the processes that drive your site.

TEST DAY TIP

The phrase store-and-forward refers to a method of delivering transmis-
sions in which the messages are temporarily held by an intermediary
before being sent on to their final destination. Some switches and many
e-mail servers use the store-and-forward method for data transfer.

EXAM WARNING

DMZ design is covered on the Security+ exam. You must know the basics
of DMZ placement and what components the DMZ divides.

In large installations, these segments may vary in placement, number, and/or
implementation, but this serves to generally illustrate the ideas behind the process.
An actual implementation may vary from this design. For example, an administrator
may wish to place all the financial processing systems on the protected network.
This is acceptable as long as the requisite security tools are in place to adequately
secure the information. I have also seen implementation of the business informa-
tion off an extension of the DMZ, as well as discrete DMZ segments for develop-
ment and testing. Specific technical requirements will impact actual deployment, so
administrators may find that what they currently have in place on a network (or
the need for a future solution) may deviate from the diagrams shown earlier.The
bottom line is to ensure that systems are protected.
