High-Pressure Sandwich Filter NOF30-05

Type Fluid Appropriate Schroeder Media Fluid NF30
®
Petroleum Based Fluids All Z-Media (synthetic) Compatibility NFS30
®
High Water Content 3, 10 and 25 µ Z-Media (synthetic)
®
Invert Emulsions 10 and 25 µ Z-Media (synthetic) YF30
Water Glycols 3, 10 and 25 µ Z-Media (synthetic)
®
CFX30
PLD

DF40
Element Element selections are predicated on the use of 150 SUS (32 cSt) Element
Pressure Series Part No. petroleum based fluid. Selection CF40
NNZX3 1NNZX3 Based on
To Flow Rate
3000 psi Z- ® NNZX10 1NNZX10 PF40
(210 bar) Media NNZX25 1NNZX25
gpm 0 12 RFS50
Flow
(L/min) 0 20 40 45
RF60
Shown above are the elements most commonly used in this housing.
Note: Contact factory regarding use of E Media in High Water Content, Invert Emulsion and Water Glycol CF60
Applications. For more information, refer to Fluid Compatibility: Fire Resistant Fluids, pages 19 and 20.
CTF60

VF60
∆P housing ∆P element Pressure
NOF30-D05 ∆P housing for fluids with sp gr = 0.86: ∆P element = flow x element ∆P factor x viscosity factor Drop LW60
Information
El. ∆P factors @ 150 SUS (32 cSt): Based on KF30
NNZX3 1.00 Flow Rate
NNZX10 .52 and Viscosity
TF50

If working in units of bars & L/min, divide above KF50
factor by 54.9.
Viscosity factor: Divide viscosity by 150 SUS (32 cSt).
KC50

MKF50

KC65

sp gr = specific gravity NOF30-05
Sizing of elements should be based on element flow information provided in the Element Selection chart above.
NOF50-760

FOF60-03
Notes ∆P filter = ∆P housing + ∆P element
Exercise: NMF30
Determine ∆P at 8 gpm (30 L/min) for
NOF301NNZX1005D5 using 150 SUS (32 cSt) fluid.
RMF60
Solution:
∆P housing = 15.0 psi [1.0 bar] Cartridge
∆P element = 8 x 0.52 x (150÷150) = 4.2 psi Elements
or
= [30 x (0.52 ÷54.9) x (32÷32) = 0.3 bar]
∆P total = 15.0 + 4.2 = 19.2 psi HS60
or
= [1.0 + 0.3 = 1.3 bar] MHS60

KFH50

SCHROEDER INDUSTRIES 123
