High Pressure Filter PLD

Type Fluid Appropriate Schroeder Media Fluid NF30
Petroleum Based Fluids All Z-Media (synthetic) Compatibility NFS30
®
®
Invert Emulsions 10 and 25 µ Z-Media (synthetic)
Water Glycols 3, 6, 10 and 25 µ Z-Media (synthetic) YF30
®
CFX30

PLD

Element DF40
Element Element selections are predicated on the use of 150 SUS (32 cSt)
Pressure Series Part No. petroleum based fluid and a 102 psi (7 bar) bypass valve. Selection
Based on CF40
10DVZ1 & 16DVZ1 10DVZ1 16DVZ1 Contact Factory Flow Rate
10DVZ3 & 16DVZ3 10DVZ3 or 16DVZ3 Contact Factory PF40
To
350 psi Z- 10DVZ5 & 16DVZ5 10DVZ5 16DVZ5 Contact
Factory
®
(24 bar) Media RFS50
10DVZ10 & 16DVZ10 10DVZ10 16DVZ10 C.F.
10DVZ25 & 16DVZ25 10DVZ25 16DVZ25 RF60
gpm 0 20 40 60 80 100
Flow CF60
(L/min) 0 50 100 150 250 380
Shown above are the elements most commonly used in this housing.
CTF60
VF60

LW60
Pressure
∆P housing ∆P element KF30
Drop
PLD ∆P housing for fluids with sp gr = 0.86: ∆P element = flow x element ∆P factor x viscosity factor
Flow (L/min) El. ∆P factors @ 150 SUS (32 cSt): Information TF50
Based on
(95) (189) (284) (378)
40 2.75 10DVZ1 16DVZ1 Flow Rate
35 .35 .23 and Viscosity KF50
30 2.06 10DVZ3 .22 16DVZ3 .18
16DVZ5
10DVZ5
25
∆P psi 20 1.375 ∆P (bar) 10DVZ10 .13 16DVZ10 .10 KC50
.09
.11
15
10 0.6875 10DVZ125 .06 16DVZ25 .05 MKF50
5 If working in units of bars & L/min, divide above factor
by 54.9.
0 Viscosity factor: Divide viscosity by 150 SUS (32 cSt).
0 20 40 60 80 200 KC65
Flow gpm
NOF30-05
sp gr = specific gravity
Sizing of elements should be based on element flow information provided in the Element Selection NOF50-760
chart above.
Notes ∆P filter = ∆P housing + ∆P element FOF60-03
Exercise: PLD16DVZ3F24VM
Determine ∆P at 75 gpm (284 L/min) for 16DVZ3 using NMF30
200 SUS (44 cSt) fluid.
RMF60
Solution:
∆P housing = 20 psi [1.38 bar]
∆P element = 75 x .18 x (200÷150) = 18 psi Cartridge
or Elements
= [284 x (.18÷54.9) x (44÷32) = 1.24 bar]
∆P total = 20 + 18 = 38 psi HS60
or
= [1.38 + 1.24 = 2.62 bar]
MHS60
KFH50

SCHROEDER INDUSTRIES 59
