Page 26 - Apollo - Top Entry Ball Valves

CLASS 300, BUTT WELD, FULL PORT

Dimensions

E E

G
(PIPE)
D D
F F
A A

B B
C C
FIGURE 1 FIGURE 2
E

G
(PIPE) D
F
A

B
C
FIGURE 3

D
F

A

B
C
FIGURE 4

ASME CLASS 300, BUTT WELD, FULL PORT Dimensions in Inches
Size A B C D E F G
1"
FIGURE 1 1.5" 1.17 3.75 7.50 5.57 6.65 3.36 NA
6.36
4.75
4.06
NA
1.50
8.40
9.50
2" 2.25 5.56 11.13 8.89 18.00 5.50 3/4” SCH.40
FIG 2 3" 3.00 7.63 15.25 9.27 30.00 5.87 3/4" SCH.40
9.00
FIGURE 3 4" 4.50 11.00 18.00 13.52 45.00 8.07 1.25" SCH.80
6"
1.25" SCH.80
9.54
22.00
14.99
45.00
6.00
FIG 4 8" 8.00 13.50 27.00 18.88* NA 13.11 NA
*Dimension to top of stem (no handle)
N-26 www.apollovalves.com Customer Service (704) 841-6000
