PAGE Series Permanent
Hose
®
A FIL Female I-Line Sanitary
Part Hose Flange Size
A A D
Number I.D. C
D C
inch mm Inch mm Inch mm Inch mm
16-16FIL 1 25 2.60 66 1.25 32 2.00 51
24-24FIL 1-1/2 38 3.43 87 1.76 45 2.00 51
Construction: Stainless Steel.
32-32FIL 2 51 4.23 107 2.26 57 2.64 67
Tubing 40-40FIL 2-1/2 64 4.42 112 2.76 70 3.31 84
84
3.31
98
3.87
123
3
48-48FIL
4.84
76
B
Coiled Air Hose & Fittings MIL Male I-Line Sanitary
®

Part
C Number Hose A Flange Size D
I.D.
C
inch mm Inch mm Inch mm Inch mm
16-16MIL 1 25 2.60 66 1.25 32 2.00 51
24-24MIL 1-1/2 38 3.43 87 1.76 45 2.00 51
Transportation Construction: Stainless Steel. 32-32MIL 2-1/2 51 4.23 107 2.26 57 2.64 67
2
70
2.76
64
3.31
4.42
84
40-40MIL
112
84
3
4.84
98
76
48-48MIL
123
3.31
3.87
D
Fittings Series PAGE FP Female NPTF Pipe Rigid
E Part Thread Hose H
Number Size I.D. A Hex
inch mm Inch mm Inch
04-04FP 1/4-18 1/4 10 1.63 41 3/4
6
7/8
1.73
44
06-06FP
3/8
3/8-18
Tooling, Equipment & Accessories Construction: Stainless Steel. 08-08FP 1-11 1/2 1/2 13 2.25 57 1-1/16
1/2-14
3/4
3/4-14
1-5/16
2.60
19
66
12-12FP
1-5/8
72
1
25
2.85
16-16FP
2
24-24FP
92
3.63
1 1/2-11 1/2
38
1-1/2
F 20-20FP 1 1/4-11 1/2 1-1/4 32 3.50 89 2-3/8
32-32FP 2-11 1/2 2 51 4.25 108 2-7/8
General Technical NOTE: The PAGE fitting call-out does not follow traditional Parker fitting nomenclature. The end size and hose size are reversed. Length calculations for PAGE
hose assemblies are typically made sealing surface to sealing surface per the NAHAD Fluoropolymer Hose Assembly Specification Guidelines unless otherwise
requested by customer at time of order.
G For detailed ordering information, please consult price list or contact Parflex Division.
