750-514 / 753-514

4 2-Channel Relay Output Module 125 V AC, 30 V DC

244 Isolated outputs; 2 changeover contacts

K1 K2
Status Status
A
relay 1 C relay 2
B
D
14 24 Data contacts
1 5
DO 1 DO 2 N 14 24 DO
11 21 Status
2 6

L 1 L 2 L
11 21
12 22
3 7
———— ———— ———
DO 1 DO 2 N DO
12 22
4 8

750-514 750-514
Power jumper contact
Fig. 750 Series
Delivered without miniature WSB markers
Control signals are transmitted from the automation device to connected
actuators via the digital output module.
The internal system voltage is used to trigger the relay.

The NO contacts are electrically isolated.
The switched status of the relay is shown by an LED.
Actuators with a ground (earth) wire may be directly connected to the module.

Description Item No. Pack. Technical Data
Unit
2DO 125V AC 0.5A/ Relay 2CO/ 750-514 1 No. of outputs 2 changeover contacts
Potential Free Current consumption typ. (internal) 70 mA
2DO 125V AC 0.5A/ Relay 2CO/ 753-514 1 Max. switching voltage 125 V AC / 30 V DC
Potential Free (without connector) Switching power 62.5 VA / 30 W
Min. switching current 0.01 mA / 10 mV DC
Max. switching current 0.5 A AC / 1 A DC
Max. switching frequency 20/min
Pull-in time (max.) 4 ms
Accessories Item No. Pack. Drop-out time (max.) 4 ms
Unit Contact material Silver alloy, gold-plated
753 Series Connectors 753-110 25 Mechanical life (min.) 1 x 10 switching operations
8
5
Coding elements 753-150 100 Electrical life (min.) 1 x 10 (0.5 A / 125 V AC)
2 x 10 (1 A / 30 V DC)
5
Miniature WSB Quick marking system Isolation 1.5 kV eff. (field/system)*;
plain 248-501 5 * 2.5 kV rated surge voltage;
with marking see Section 11 Overvoltage category III
Approvals Internal bit width 2 bits
Wire connection CAGE CLAMP ®
Conformity marking 1 Cross sections 0.08 mm² ... 2.5 mm² / AWG 28 ... 14
Korea Certification Strip lengths, 750/753 Series 8 ... 9 mm / 0.33 in
Marine applications ABS, BV, DNV, GL, KR, LR, NKK, PRS, RINA 9 ... 10 mm / 0.37 in
r UL 508 Width 12 mm
Weight 49.5 g
EMC immunity of interference acc. to EN 61000-6-2, marine applications
EMC emission of interference acc. to EN 61000-6-4, marine applications
