Technical Specifications

Dimensions and Weights
(External bridge, European sizes - Frame E)

Dimensioni e Pesi
Dimensions et Poids
Abmessungen und Gewichte
Dimensiones y Pesos
The 12 pulses DC drives are composed by two
identical bridges and two Control Units, the
dimensions and weigth showed below refers to d1 25
one bridge only.
I convertitori DC a 12 impulsi sono composti
da 2 ponti esterni e 2 Unità di Controllo 510
identiche, le dimensioni e i pesi indicati sotto si C d2
riferiscono a un solo ponte. TPD32 CU b
Les convertisseurs CC à 12 impulsions sont
constitués de 2 ponts externes et de 2 unités d 470
de contrôle identiques ; les dimensions et les
poids indiqués ci-dessous se réfèrent à un
seul pont. D d2
Die DC-Stromrichter mit 12 Impulsen bestehen 535
aus 2 externen Brücken und 2 identischen
Steuereinheiten; die unten angegebenen Maße d1
und Gewichte beziehen sich auf eine einzige 1200 cable length 25
Brücke. (included) U V W f TPD32-EV-...-3300-E e
Los convertidores CC de 12 impulsos constan a1 a2 a1 c
de 2 puentes externos y 2 unidades de control
idénticos; las dimensiones y los pesos que se a
muestran a continuación se refieren a un solo
puente.
TPD32 EV-...-2B-E a b c d e f a1 a2 d1 d2 Weight (1)
European Drive Rating mm [inches] mm [inches] mm [inches] mm [inches] mm [inches] mm [inches] mm [inches] mm [inches] mm [inches] mm [inches] kg (lbs]
TPD32 EV-690/840-1010-2B 500 [19.7] 760 [29.9] 275 [10.8] 550 [21.7] 153 [6.0] 95 [3.7] 10 [0.39] 480 [18.9] 50 [2.0] 225 [8.9] 70 [154.3]
TPD32 EV-500/600-1200-2B 500 [19.7] 570 [22.4] 275 [10.8] 360 [14.2] 153 [6.0] 75 [3.0] 10 [0.39] 480 [18.9] 50 [2.0] – 65 [143.3]
TPD32 EV-690/840-1400-2B 500 [19.7] 760 [29.9] 275 [10.8] 550 [21.7] 153 [6.0] 95 [3.7] 10 [0.39] 480 [18.9] 50 [2.0] 225 [8.9] 70 [154.3]
TPD32 EV-500/600-1500-2B 500 [19.7] 760 [29.9] 275 [10.8] 550 [21.7] 153 [6.0] 95 [3.7] 10 [0.39] 480 [18.9] 50 [2.0] 225 [8.9] 70 [154.3]
TPD32 EV-690/840-1700-2B 620 [24.4] 764 [30.1] 360 [14.2] 550 [21.7] 233 [9.2] 95 [3.7] 10 [0.39] 600 [23.6] 50 [2.0] 225 [8.9] 100 [220.5]
TPD32 EV-500/600-1800-2B 500 [19.7] 760 [29.9] 275 [10.8] 550 [21.7] 153 [6.0] 95 [3.7] 10 [0.39] 480 [18.9] 50 [2.0] 225 [8.9] 70 [154.3]
TPD32 EV-500/600-2000-2B 500 [19.7] 760 [29.9] 275 [10.8] 550 [21.7] 153 [6.0] 95 [3.7] 10 [0.39] 480 [18.9] 50 [2.0] 225 [8.9] 70 [154.3]
TPD32 EV-690/840-2000-2B 620 [24.4] 764 [30.1] 360 [14.2] 550 [21.7] 233 [9.2] 95 [3.7] 10 [0.39] 600 [23.6] 50 [2.0] 225 [8.9] 100 [220.5]
TPD32 EV-500/600-2400-2B 620 [24.4] 764 [30.1] 360 [14.2] 550 [21.7] 233 [9.2] 95 [3.7] 10 [0.39] 600 [23.6] 50 [2.0] 225 [8.9] 100 [220.5]
TPD32 EV-690/840-2400-2B 712 [28.0] 775 [30.5] 395 [15.6] 560 [22.2] 255 [10.0] 95 [3.7] 10 [0.39] 692 [27.2] 50 [2.0] 230 [9.1] 140 [308.6]
TPD32 EV-500/600-2700-2B 712 [28.0] 785 [30.9] 395 [15.6] 660 [26.0] 255 [10.0] 95 [3.7] 10 [0.39] 692 [27.2] 50 [2.0] 280 [11.0] 140 [308.6]
TPD32 EV-690/840-2700-2B 712 [28.0] 775 [30.5] 395 [15.6] 560 [22.2] 255 [10.0] 95 [3.7] 10 [0.39] 692 [27.2] 50 [2.0] 230 [9.1] 140 [308.6]
TPD32 EV-500/600-2900-2B 712 [28.0] 775 [30.5] 395 [15.6] 560 [22.2] 255 [10.0] 140 [5.5] 10 [0.39] 692 [27.2] 50 [2.0] 230 [9.1] 140 [308.6]
TPD32 EV-500/600-3300-2B 780 [30.7] 1180 [46.5] 420 [16.5] 875 [34.4] 295 [11.6] 125 [4.9] 25 [1.0] 730 [28.7] 25 [1.0] 300 [11.8] 260 [573.2]
TPD32 EV-690/840-3300-2B 780 [30.7] 1180 [46.5] 420 [16.5] 875 [34.4] 295 [11.6] 125 [4.9] 25 [1.0] 730 [28.7] 25 [1.0] 300 [11.8] 260 [573.2]
Technical Specifications TPD32 EV-690/720-1010-4B mm [inches] 1310 [51.6] mm [inches] mm [inches] mm [inches] mm [inches] mm [inches] mm [inches] mm [inches] mm [inches] 130 [286.6]
TPD32 EV-...-4B-E
Weight (1)
f
a1
d2
a
b
c
e
d
d1
a2
European Drive Rating
kg (lbs]
mm [inches]
480 [18.9]
95 [3.7]
153 [6.0]
550 [21.7]
375 [14.8]
50 [2.0]
10 [0.39]
225 [8.9]
500 [19.7]
130 [286.6]
225 [8.9]
550 [21.7]
50 [2.0]
95 [3.7]
153 [6.0]
10 [0.39]
480 [18.9]
1310 [51.6]
375 [14.8]
TPD32 EV-690/720-1400-4B
500 [19.7]
225 [8.9]
130 [286.6]
1310 [51.6]
10 [0.39]
480 [18.9]
500 [19.7]
95 [3.7]
TPD32 EV-500/520-1500-4B
153 [6.0]
50 [2.0]
550 [21.7]
375 [14.8]
153 [6.0]
500 [19.7]
50 [2.0]
375 [14.8]
TPD32 EV-500/520-1700-4B
480 [18.9]
10 [0.39]
550 [21.7]
130 [286.6]
95 [3.7]
1310 [51.6]
225 [8.9]
TPD32 EV-690/720-1700-4B
50 [2.0]
TPD32 EV-500/520-2000-4B
480 [18.9]
225 [8.9]
130 [286.6]
1310 [51.6]
375 [14.8]
550 [21.7]
153 [6.0]
10 [0.39]
500 [19.7]
95 [3.7]
TPD32 EV-690/720-2000-4B 620 [24.4] 1314 [51.7] 475 [18.7] 550 [21.7] 233 [9.2] 95 [3.7] 10 [0.39] 600 [23.6] 50 [2.0] 225 [8.9] 170 [374.8]
225 [8.9]
170 [374.8]
620 [24.4]
95 [3.7]
10 [0.39]
233 [9.2]
475 [18.7]
550 [21.7]
1314 [51.7]
600 [23.6]
50 [2.0]
TPD32 EV-500/520-2400-4B 620 [24.4] 1314 [51.7] 495 [19.5] 550 [21.7] 233 [9.2] 95 [3.7] 10 [0.39] 600 [23.6] 50 [2.0] 225 [8.9] 170 [374.8]
TPD32 EV-690/720-2400-4B 712 [28.0] 1335 [52.6] 475 [18.7] 560 [22.0] 255 [10.0] 95 [3.7] 10 [0.39] 692 [27.2] 50 [2.0] 230 [9.1] 240 [529.1]
TPD32 EV-500/520-2700-4B 712 [28.0] 1535 [60.4] 490 [19.3] 660 [26.0] 255 [10.0] 100 [3.9] 10 [0.39] 692 [27.2] 50 [2.0] 280 [11.0] 240 [529.1]
TPD32 EV-690/720-2700-4B 712 [28.0] 1335 [60.4] 475 [18.7] 560 [22.0] 255 [10.0] 95 [3.7] 10 [0.39] 692 [27.2] 50 [2.0] 230 [9.1] 240 [529.1]
TPD32 EV-.../...-3300-4B 780 [30.7] 1890 [74.4] 470 [18.5] 1585 [62.4] 315 [12.4] - 25 [1.0] 730 [28.7] - - 435 [959]
