Eaton Gas/Liquid Separator Applications

Steam The Exclusive Eaton
Eaton Gas/Liquid Separators Vortex Containment
are often installed ahead of Vortex Containment
Plate (VCP) prevents
steam turbines to protect Plate (VCP) re-entrainment of
the turbine blades from the separated liquid.
erosive action of wet steam, In the past, separators have
pipe scale, and other damage- often operated at less than
causing entrained solids. They peak efficiency due to the
are also installed in steam re-entrainment of separated
distribution lines to assure liquid at normal or high flow
clean, dry steam enters heat rates. The Eaton VCP solves
exchangers, pressure reducing this problem. The VCP utilizes
valves, temperature regulators, carefully placed rings that
meters, and other process shield the separated liquid
equipment. from the vortex action inside Separator A without the Vortex Containment Plate
the separator and direct it to
Compressed Air the separator drain. The
turbulence of the swirling gas
Compressed air lines have or air flow is sheltered from
Eaton Gas/Liquid Separators the liquid and cannot be
installed following intercoolers re-entrained after separation.
and aftercoolers to remove The VCP features extremely
entrained moisture that would heavy duty construction,
otherwise cause damage in unlike the delicate baffles
successive stages of used by other systems. And
compression or to subsequent the Eaton VCP is completely
processes. They are used for maintenance free. Separator B without the Vortex Containment Plate
entrainment removal in The charts on the right
primary air lines leading to graphically depict the high
air-using equipment such as efficiency of Eaton’s exclusive
air chucks, air nozzles, and Vortex Containment Plate.
paint spray equipment. They They show the percentage
are particularly suitable for efficiency versus air flow
long runs of pipe and where when the separator is
wide temperature differentials operated at 1 and 3 atm with
are found. The units are a water input rate of 150
highly efficient for moisture pounds per hour. Two typical
separation of refrigerated 3” gas/liquid separators that
air dryer packages. do not contain the Eaton
Vortex Containment Plate are Type 31-L Separator with the Vortex Containment Plate
Compressed Gas compared to a Type 31L Eaton
Separator. The performance
Eaton Gas/Liquid Separators standard was the removal of
are used in conjunction with all liquid and solid entrainment
intercooler and aftercooler where particle sizes exceeded
equipment installed on gas 10 microns.
compressors. They are very
effective in the removal of oil,
tar, water, and other unwanted
entrainment.
