Gas/Liquid Separation Fabricated Construction

Gas/Liquid Separators
Type T

Fabricated

Construction

• Custom Sizes

• Carbon Steel or Stainless Steel

FEATURES
• Fabricated Construction
• High Efficiency Over Wide Flow Range
• No Required Maintenance
• Economical Choice for Most Applications
• Removes 99% of Liquid and Solid Entrainment
Particles Larger Than 10 Microns High Efficiency – Application Flexibility
• Gas, Steam, or Air Applications No Maintenance
Fabricated separators are
The Eaton Type T Gas/Liquid manufactured one at a time
OPTIONS Separator automatically and are made to fit the exact
• ASME UM or U Code Stamp removes 99% of all liquid and requirements of unusual
applications with unique size
solid entrainment particles 10
• Hundreds of Design Options to microns in size or larger from or piping connections. They
Conform to Application Requirements air, gas, and steam processes. are lighter in weight than a
• Support Legs And it does so with no moving comparable size cast separator.
parts to wear out and with There are no trade-offs with a
no required maintenance. The fabricated separator. You get
Type T, with its cost-effective the perfect unit for your
design, is the separator of application. You never have to
choice for most applications pay for more separator than
that require clean, dry air, gas you need, or settle for a
or steam. separator that won’t quite do
the job you want it to.
Exclusive Design
Fabricated Construction
Moisture-laden gas enters the
inlet of the separator where Fabricated Type T Gas/Liquid
it is deflected in a centrifugal Separators are available in
downward motion. The sizes from 1” to 24” in carbon
entrained solids and moisture steel or stainless steel
droplets are separated out construction. Fabricated
by a reduction in velocity. construction separators are
Separated liquid and solids built to order and can be easily
fall into a reservoir where manufactured to exactly meet
the exclusive Eaton Vortex the requirements of special
Containment Plate (VCP) applications or applications
ensures that they cannot be where weight is a concern.
re-entrained. The clean, dry
flow is then directed to the
outlet by the VCP. This
eliminates the need for
expensive, delicate baffles
used in ordinary separators.
