Gas/Liquid Separation Fabricated Construction

Gas/Liquid Separators
DTL

Dry Type

• For High Solid Loading Applications Type T-DTL

• Sizes from 2” to 16”

FEATURES
• Removes 99% of Liquid and Solid Entrainment
Particles Larger Than 10 Microns
• No Required Maintenance
• Low Pressure Drop
• Flanged Drain Type 33L-DTL
• Fabricated Carbon or Stainless Steel Construction
OPTIONS
• Larger Sizes
• Code Stamp

Eaton’s Dry Type Gas/Liquid When correctly specified and
Separators are designed for installed, DTL separators will
applications with higher than remove 99% of all entrained
normal loads of entrained liquid droplets and solid
solids. In order to handle the particles that are 10 microns in
large amount of solids, these size or larger from an air, gas,
separators feature a cone- or steam stream. The removed
shaped sump that does a particles and liquid accumulate Type 31L-DTL
better job of collecting at the drain port at the bottom
removed solids at the drain of the drain sump for removal.
port. The separated material
must be removed before it Centrifugal Action
fills the sump area. Since
automatic drain traps are not The Type DTL separators separated particles
suitable for handling solid cause the gas stream to enter and liquid droplets
materials, the use of a rotary a controlled centrifugal flow, from the vortex action
valve is recommended for this which forces any entrained within the separator
purpose. This allows the solid liquids and solids to the outer and directs them Type DTL Separators are
material to be removed while wall. The exclusive Eaton toward the drain sump. The available in three different
releasing a minimum amount Vortex Containment Plate exit stream is drawn from the configurations. The Type T-DTL
of air, gas, or steam from the (VCP) system shields these clean, dry center of the has a straight-through flow
system. separator. The VCP prevents connection, the 33L-DTL has a
re-entrainment of the removed vertical downflow inlet and a
liquids and solids and assures horizontal outlet, and the
a clean, dry gas stream at the 31L-DTL is a compact,
separator outlet. straight-through flow design.
