P. 31
Gas/Liquid Separation Construction
Gas/Liquid Cast
Float Drain Traps
Type 230-AC
Type 350-AC
• Drain Condensate from Type 90-AC
Gas/Liquid Separators
FEATURES
• No Priming Required
• Stainless Steel Internal Parts
• Internal Parts Removed with Cover
• No Loss of Line Pressure
• Choice of Inlet/Outlet Configurations
Eaton Float Drain Traps inoperative
OPTIONS efficiently handle the liquids in • Vertical inlet, down-flow
the storage tanks and drip discharge design
• Heater for Low Temperature Applications points of separators without
pressure loss in the line. • Ample float power and a
These traps are capable of large outward opening
removing up to 2800 pounds discharge valve prevent loss
of condensate per hour and of pressure
work with pressure • Internal parts are stainless
Typical Float Drain Trap Installations differentials from 5 up to 250 steel, including a non-
psi. magnetic valve and seat
• Working parts are attached
Type 90-AC and 95-AC to the cover for easy removal
Float Drain Traps
without disconnecting the
• Cast iron, cast carbon steel, trap from the line.
or cast stainless steel for • No priming is required
0 to 500 psi service
• For low temperature
• A positive water seal applications, a heater is
prevents loss of air or gas available as an option
• Straight-through design
• Internal parts, including Type 350-AC
the valve and seat, are Float Drain Traps
corrosion-resistant, These ball float traps feature a
non-magnetic stainless steel “Three-Traps-In-One” design.
• Working parts are attached Three valves open and close
to the base for easy progressively as condensate
Type 230-AC Installation Type 90-AC Installation removal and inspection volume varies. When the float
chamber water level rises, the
• A side inlet/outlet ball float lies deep in the water
configuration is available for until its buoyancy overcomes
iron, carbon steel, and the opposing line pressure and
stainless steel traps snaps the valve wide open.
When closing, as each valve
Type 230-AC approaches its seat, the line
Float Drain Traps pressure snaps it tightly in
• Cast iron for 0 to 125 psi place. These traps have cast
service, ideal where gummy iron bodies, and stainless
emulsions or cylinder steel, or copper internal parts.
lubricants make other traps
