Suction Cups for High-Temperature Applications
Flat Suction Cups SAF HT2
PA01019111_inh_EN.pdf Suction area (Ø) from 30 mm to 60 mm PA01019111_inh_EN.pdf

container
Suitable for Industry Specific Applications
Schmalz - The Company

container
Applications
• Round, flat suction cups for dynamic handling of hot metal sheets Vacuum Knowledge
up to 250 °C (short cycle times)
• Unloading of parts after forming
• Handling of thin aluminum sheets without deformation or deep Suction Cups
drawing Vacuum
• For use e.g. in feeder systems for press lines in the automobile
industry
Special Grippers

Vacuum Grip- ping Systems
Flat suction cups SAF HT2
container
Design

• Robust and wear-resistant suction cup SAF made of HT2 with
special inner support Mounting Elements
• Suction cup SAF vulcanized to the connection nipple (very high
strength)
Vacuum Generators

Valve Technology

System design flat suction cup SAF HT2
Switches and
container
Our Highlights... Your Benefits... Monitoring
• Silicone-free special material >Absence of PWIS (paint wet-
HT2 ting impairment substances),
temperature resistance up to
250 °C long term Filters and Connections
• Large structured inner support >No deep drawing of the
workpiece; capable of
handling high lateral forces
• Soft and flexible sealing lip >Good sealing, even on slightly Services
curved surfaces

Contact
Flat suction cup SAF HT2 for handling formed sheet metal parts

Index of Products

container
www.schmalz.com/saf-ht2
